Liquid Food Suction & Discharge Hose, Gray, 3.66 Inch OD, 3.00 Inch ID, Up To 150.00 PSI

Ask A Question

Description & Features

This Eaton Industrial Hose is a Lemur series suction and discharge hose designed for transferring liquid food products. The gray hose has a 3.00-inch inside diameter (ID) and a 3.66-inch outside diameter (OD). Suitable for applications requiring a flexible connection with a pressure rating up to 150.00 PSI. This Liquid Food Suction & Discharge Hose ensures reliable performance in demanding environments.

Refer to the Eaton fluid compatibility document to ensure that the hose is appropriate for the conveyed media.

SKU: EHF002-48GY-100

Supplier Part Number (MPN): EHF002-48GY-100

Alternate Part Numbers: C1MK79, EHF002-48-100, MI-08753220, MINO-00015X93355

Specifications

Brand
Aeroquip® by Danfoss
Conductivity
Conductive
Cover Material
NVC Blend
Dash Size
48
For Use With
Cam and Groove and Combination Nipple Hose Fittings
grp Construction
Vegetable Oil-Resistant NBR Tube, FDA Approved Material; High-Tensile Synthetic Textile with A Single Steel Helical Wire Reinforcement; Oil, Abrasion, Ozone and Weather-Resistant Synthetic Rubber Cover
grp Fitting Attachment
Band-It® Jr, Preformed Clamps, Band and Buckle
grp Fittings
Cam and Groove, Combination Nipple
grp Fittings Fitting Attachment Suggestions
Cam and Groove, Combination Nipple
Hose Color
Gray
Hose Type
Food and Beverage
Inside Diameter
3 in
Lay Line Style
Ink Transfer
Nominal Size
#03
Qualified Hose Fittings
Cam and Groove
Reinforcement
4-Ply Braided Fabric
Resistance Properties
Abrasion
Series
EHF002 Series
Tube Material
NBR
Vacuum Service
28

Similar Products

Model Number Color Hose I.D. Hose O.D. Maximum Operating Pressure Burst Pressure Vacuum Service Reel Qty (ft) Price Action
Liquid Food Suction & Discharge Hose, Gray, 2.06 Inch OD, 1.50 Inch ID, Up To 150.00 PSI

EHF002-24GY-100 Liquid Food S & D Hose

Gray

1.5

2.06

150

28

100

Liquid Food Suction & Discharge Hose, Gray, 2.60 Inch OD, 2.00 Inch ID, Up To 150.00 PSI

EHF002-32GY-100 Liquid Food S & D Hose

Gray

2

2.6

150

28

100

Liquid Food Suction & Discharge Hose, Gray, 4.67 Inch OD, 4.00 Inch ID, Up To 150.00 PSI

EHF002-64GY-100 Liquid Food S & D Hose

Gray

4

4.67

150

28

100

Product Questions & Answers (4)

Question by: Harold A on Dec 13, 2025, 12:03 PM
Can this hose handle vegetable oil without breaking down?
Answer by: Customer Support on Dec 15, 2025, 6:38 AM
Indeed, the hose has a vegetable oil-resistant NBR tube made from FDA-approved material, so it stands up to oils.
Question by: Troy W on Sep 24, 2025, 1:31 PM
What’s the outside diameter on this hose? Just want to make sure it’ll fit my setup.
Answer by: Customer Support on Sep 26, 2025, 6:02 AM
The outside diameter measures 3.66 inches.
Question by: Troy W on Jul 26, 2025, 5:22 PM
got a 3-inch line running product through a food processing setup, will this hose hold up to that kind of continuous transfer work?
Answer by: Customer Support on Jul 28, 2025, 10:07 AM
For food and beverage transfer lines, a 3-inch ID is exactly what this hose is built around. The 3.00 inch inner diameter keeps flow consistent across suction and discharge applications, and the 150 PSI working pressure gives you solid headroom for typical processing line pressures. Gray color also makes it straightforward to keep separated from hoses used in other service categories on the floor.
Question by: Donna W on Apr 6, 2025, 3:32 PM
got a 3 inch line here, is this hose actually 3.00 inch inside or is that just a “nominal” thing
Answer by: Customer Support on Apr 8, 2025, 6:49 AM
The inside diameter on this one is listed at 3.00 inch ID, with a 3.66 inch outside diameter, so it matches a 3 inch flow path on the inside.
