BRENNAN 04IN-08STDPIPE STNLS

A stainless steel male tube-to-pipe adapter from Brennan Industries' N2406 series, this fitting connects a 1/4 in. OD tube to a 1/2 in. standard pipe thread end. The stainless steel construction makes it well suited for hydraulic and fluid system applications where corrosion resistance is a priority.

Dimensional references from the N2406 series place the overall length at 46.3 mm, with a 17.8 mm C dimension and a 15.3 mm D dimension. The minimum E dimension is 4.8 mm, and both the tube-side and pipe-side hex measure 14 mm across the flats. The Brennan 04IN-08STDPIPE Stnls is a practical choice where a compact, corrosion-resistant male adapter is needed in stainless steel for mixed-size tube and pipe connections.

SKU: N2406-04-08-SS

Supplier Part Number (MPN): N2406-04-08-SS
