06IN-06STDPIPE Stnls

Description & Features

Constructed from stainless steel, this male NPT to standard pipe adapter is part of Brennan Industries' N2406 series and is sized for 3/8 in. tube OD connections on both ends. The stainless steel construction makes it well suited for hydraulic and fluid power systems where corrosion resistance is a priority.

The 06IN-06STDPIPE Stnls carries key dimensional values including an A dimension of 43.2 mm, a C dimension of 19.3 mm, and a D dimension of 16.8 mm. The minimum E dimension is 7.1 mm, with across-flat measurements of 16 mm and 17 mm for the F and G dimensions respectively. These characteristics make it a reliable choice for inline connections in industrial fluid systems requiring a durable, corrosion-resistant fitting.

SKU: N2406-06-06-SS

Supplier Part Number (MPN): N2406-06-06-SS

Specifications

a Dimensions 43.2 mm	c Dimensions 19.3 mm	Connection Size 1 3/8 in	Connection Size 2 3/8 in	Connection Type Stub End, Compression	Connection Type 1 Tube Compression	Connection Type 2 Stub End	d Dimensions 16.8 mm	Dimensions 1.7 in L	e Min Dimensions 7.1 mm	FAF Dimensions 16 mm	Fitting Type Adapter	gaf Dimensions 17 mm	Hex Size 5/8 in	Material Stainless Steel	Material Construction 316L Stainless Steel	Series N2406 Series	Thread Size 9/16-20

Product Questions & Answers (1)

Question by: Melvin P on Mar 14, 2026, 6:29 PM

Will this fitting hold up to corrosive fluids, or should I be looking at something else?

Answer by: Customer Support on Mar 16, 2026, 7:22 AM

Constructed from stainless steel, this adapter offers good corrosion resistance, making it suitable for hydraulic systems that handle corrosive fluids.
