06IN-06IN90

Description & Features

Constructed from stainless steel, this 3/8 in. tube OD, 90-degree male connector is part of the Brennan Industries N2500 Series and is designed for right-angle hydraulic tube connections where corrosion resistance is a priority. The 90-degree configuration suits installations where straight-line routing is not practical, helping to manage directional changes within tight assemblies.

The 06IN-06IN90 carries key dimensional values including a 30.5 mm A dimension, 19.3 mm C, 16.8 mm D, and a 17 mm across-flats (AF) measurement, with an HX of 23.2 mm. The minimum E dimension is 7.1 mm. Stainless steel construction makes this fitting suitable for hydraulic circuits exposed to moisture, chemicals, or other corrosive conditions that would compromise standard carbon steel components.

SKU: N2500-06-06-SS

Supplier Part Number (MPN): N2500-06-06-SS

Specifications

Brand
BRENNAN
a Dimensions
30.5 mm
c Dimensions
19.3 mm
Connection Size 1
3/8 in
Connection Size 2
3/8 in
Connection Type
Compression
Connection Type 1
Compression
Connection Type 2
Compression
d Dimensions
16.8 mm
Dimensions
0.91 in L
e Min Dimensions
7.1 mm
FAF Dimensions
17 mm
Fitting Type
90 deg Elbow
g Dimensions
17 mm
Hex Size
5/8 in
Material
Stainless Steel
Material Construction
316L Stainless Steel
Series
N2500 Series
Thread Size
9/16-20

Similar Products

Model Number Connection Size 1 Connection Size 2 Thread Size Price Action
BRENNAN 5/16 TUBE X TUBE ELBOW SS

N2500-05-05-SS

5/16 in

5/16 in

1/2-20

12IN-12IN 90DEG Stnls

N2500-12-12-SS

3/4 in

3/4 in

1-20

16IN-16IN 90DEG Stnls

N2500-16-16-SS

1 in

1 in

5/16-20

Product Questions & Answers (1)

Question by: Marvin F on Dec 8, 2025, 4:36 PM
Would this fitting hold up alright if it was exposed to some chemicals?
Answer by: Customer Support on Dec 10, 2025, 2:49 PM
Given its stainless steel construction, this fitting should perform well in environments where it's exposed to chemicals or moisture.
