06IN-06IN-04FNPT

Description & Features

This stainless steel adapter features a 3/8 inch tube OD, with 1/4 inch female NPT connection. The 06IN-06IN-04FNPT adapter, part of the N2602 series, is expertly crafted by Brennan Industries.

Key dimensions include a Brennan A measurement of 62.4 mm, Brennan Ax measurement of 31.2 mm, and Brennan B measurement of 15.0 mm.

SKU: N2602-06-06-04-SS

Supplier Part Number (MPN): N2602-06-06-04-SS

Specifications

a Dimensions 62.4 mm	ax Dimensions 31.2 mm	b Dimensions 15 mm	c Dimensions 19.3 mm	Connection Size 1 3/8 in	Connection Size 2 3/8 in	Connection Type 1 Compression	Connection Type 2 Compression	Connection Type 3 FNPT	d Dimensions 16.8 mm	Dimensions 0.94 in L	e Min Dimensions 7.1 mm	FAF Dimensions 16 mm	Fitting Type Tee	gaf Dimensions 16 mm	Hex Size 0.81 in	hy Dimensions 22.4 mm	Material Stainless Steel	Material Construction 316L Stainless Steel	Series N2602 Series	Thread Size 9/16-20

Product Questions & Answers (1)

Question by: Joyce A on May 18, 2025, 6:32 PM

Will this adapter hold up for connecting some hydraulic lines on my tractor?

Answer by: Customer Support on May 19, 2025, 8:05 PM

This stainless steel adapter is designed for connecting a 3/8 inch tube OD to a 1/4 inch female NPT connection. It should work well for hydraulic lines, assuming those connection sizes are right.
