DB FERRULE 1/8 TEE BRASS

Ask A Question

Description & Features

Designed for 1/8 in. tube OD connections, the DB Ferrule 1/8 Tee Brass is a double-bite ferrule fitting manufactured by Brennan Industries in the N2603-B series. The tee configuration supports three-way tube connections in a compact brass body, making it well-suited for instrumentation, fluid control, and hydraulic line distribution applications.

Brass construction provides reliable corrosion resistance across a broad range of hydraulic and industrial fluids. Key dimensional references include an overall length (A) of 44.8 mm, a hex flat measurement of 11 mm across all ports, and a tube bore (D) of 12.7 mm, with a minimum ferrule engagement (E) of 2.4 mm. The fitting is classified as a male-end configuration and is compatible with standard double-ferrule compression tube assemblies.

SKU: N2603-02-02-02-B

Supplier Part Number (MPN): N2603-02-02-02-B

Specifications

Brand
BRENNAN
ax Dimensions
22.4 mm
c Dimensions
15.3 mm
Connection Size 1
1/8 in
Connection Size 2
1/8 in
Connection Type
Compression
Connection Type 1
Compression
Connection Type 2
Compression
Connection Type 3
Compression
d Dimensions
12.7 mm
Dimensions
0.62 in L
e Min Dimensions
2.4 mm
FAF Dimensions
11 mm
Fitting Type
Tee
gaf Dimensions
11 mm
Hex Size
3/8 in
Material
Brass
Material Construction
CA377 Brass
Series
N2603 Series
Thread Size
5/16-20

Product Questions & Answers (1)

Question by: Jimmy R on Apr 28, 2025, 6:52 AM
Can this tee fitting handle standard hydraulic pressures without leaking at the connections?
Answer by: Customer Support on Apr 29, 2025, 9:27 PM
This brass tee is designed for use in hydraulic line distribution. The double-bite ferrule design ensures a secure connection that should prevent leaks under normal hydraulic pressures.
