PFR2-10 Series 3-Port Pressure Compensated Priority Flow Control Cartridge Valves, Up To 3000 PSI & 10 GPM Regulated

Description & Features

Application	This valve maintains a constant priority flow from port 1 to port 3 based on the setting adjustment, regardless of pressure changes downstream on port 3. Flow in excess of the priority setting is directed to port 2. If the priority flow at port 3 is blocked, the spool will shift to satisfy the priority flow requirement, thereby closing off flow to port 2.
Cartridge	Model PFR2-10*, sold separately.
Features	Cartridge style (Requires a machined cavity or housing for installation). The flow adjustment range is from the factory set maximum flow rate down to 50% of that rate. Pressure compensated for accurate flow control regardless of changes in input or load pressure.
Housing	Cavity size C-10-3, sold separately, see
Maximum Flow Rate	15 GPM (Inlet), 10 GPM (Priority).
Maximum Operating Pressure	3000 PSI.
Recommended Filtration	ISO 4406 Cleanliness Level 18/16/13 or cleaner.
Temperature Range	-40°F to 248°F (Extreme Limits).

Model Number	Part Number	Adjustable Range	Adjustment Style	Housing	Seal Material	Price	Action
PFR2-10-S-0/12.00 PFR2-10 Series Cartridge Valve	02-165669	6.0 - 12.0	Screw with Locknut	None	Buna-N

Question by: Dwayne W on Jul 30, 2025, 12:55 PM

Reckon this'll fit in a C-10-3 cavity I already got set up?

Answer by: Customer Support on Aug 1, 2025, 6:36 AM

This cartridge valve is designed to fit a C-10-3 cavity. You'll need to get the housing separately though.
