Polyethylene Tubing, 0.31 OD, 0.06 Thick, 0.19 ID, Up To 230.00 PSI

Description & Features

The Freelin Wade polyethylene tubing offers robust performance in general low pressure and low temperature applications. With an O.D. of 0.313 in and a wall thickness of 0.062 in this tubing is designed to withstand a maximum operating pressure of 230 PSI making it suitable for a variety of industrial applications including instrumentation and food processing.

Key advantages of this tubing include its superior environmental stress crack resistance (ESCR) compared to low density polyethylene providing enhanced durability against chemical exposure aging and high vibration connections. The natural color tubing complies with FDA regulation 21 CFR 177.1520(c) for food contact.

Designed with a burst pressure of 920 PSI and a minimum bend radius of 1.5 inches this polyethylene tubing maintains flexibility and strength. The temperature range for optimal performance extends from -40deg;F to 150deg;F. The tubing also complies with FDA and NSF51 requirements ensuring safety and reliability.

Supplier Part Number: 1J-077-10

MPN: 1J-077-10

Specifications

Brand
Freelin-Wade®
Color
Natural
For Use With
Push-In, Compression Fittings
grp Tolerance
+/-0.004 in
Hardness
50 Shore D
Inside Diameter
3/16 in
Material
Polyethylene
Material Construction
LLDPE
Nominal Size
5/16 in
Resistance Properties
Crack

Similar Products

Model Number Nominal Size Inside Diameter Outside Diameter Length Color Wall Thickness Price Action
Polyethylene Tubing, 0.25 OD, 0.04 Thick, 0.17 ID, Up To 200.00 PSI

1J-048-10 Polyethylene Tubing

1/4 in

0.17 in

Natural

Polyethylene Tubing, 0.13 OD, 0.03 Thick, 0.06 ID, Up To 305.00 PSI

1J-109-10 Polyethylene Tubing

Natural

Polyethylene Tubing, 0.25 OD, 0.04 Thick, 0.17 ID, Up To 200.00 PSI

1J-048-01 Polyethylene Tubing

1/4 in

0.17 in

Black

Polyethylene Tubing, 0.38 OD, 0.06 Thick, 0.25 ID, Up To 190.00 PSI

1J-074-10 Polyethylene Tubing

3/8 in

1/4 in

Natural

Polyethylene Tubing, 0.19 OD, 0.03 Thick, 0.13 ID, Up To 200.00 PSI

A43184 Polyethylene Tubing

0.12 in

Natural

FW BLK PE 3/8 X 1/4 X 100 FT BAG

1J-074-01

3/8 in

1/4 in

Black

FW NAT PE 1/2 X 3/8 100 FT BAG

1J-076-10

1/2 in

0.38 in

Natural

FW NAT PE 5/32(4MM) X .106(2.7MM) X 100 FT BAG

1J-189-10

0.11 in

Natural

Product Questions & Answers (1)

Question by: Terry G on Nov 6, 2025, 3:53 PM
got a 5/16 line now, is this the same size or am i gonna be fighting it on the fittings
Answer by: Customer Support on Nov 8, 2025, 6:48 AM
You are looking at 5/16 inch OD tubing. The outside diameter is 0.313 in and the inside diameter is 0.187 in with a 0.062 in wall, so it matches what most folks mean when they say 5/16 OD.
