Polyethylene Tubing, 0.13 OD, 0.03 Thick, 0.06 ID, Up To 305.00 PSI

Description & Features

FreelinWade offers a versatile solution with 0.13 OD Polyethylene Tubing. The natural color tubing featuring a 0.031-inch wall thickness is ideal for general low pressure and low temperature applications including instrumentation and food processing. Its design emphasizes superior environmental stress crack resistance (ESCR) thanks to the use of linear low density polyethylene which extends service life even under chemical exposure and high vibration conditions.

Minimum Bend Radius: 0.5 inches

Maximum Operating Pressure: Up to 305 PSI

Temperature Range: -40deg;F to 150deg;F

Pressure Rating: 3:1 Safety Factor

Vacuum Rating: To 28"Hg

All colors comply with FDA regulation 21 CFR 177.1520copy; for food contact applications ensuring safe use in sensitive environments. The tubing's hardness is rated at 50 Shore D and it has a tolerance of +/- 0.004". The burst pressure is noted at 1220. Compliance with FDA and NSF51 standards further validates its reliability and efficiency.

Supplier Part Number: 1J-109-10

Catalog Number: C1MJ15

Specifications

Brand
Freelin-Wade®
Color
Natural
For Use With
Push-In, Compression Fittings
grp Tolerance
+/-0.004 in
Hardness
50 Shore D
Material
Polyethylene
Material Construction
LLDPE
Resistance Properties
Crack

Similar Products

Model Number Nominal Size Inside Diameter Outside Diameter Length Color Wall Thickness Price Action
Polyethylene Tubing, 0.25 OD, 0.04 Thick, 0.17 ID, Up To 200.00 PSI

1J-048-10 Polyethylene Tubing

1/4 in

0.17 in

Natural

Polyethylene Tubing, 0.25 OD, 0.04 Thick, 0.17 ID, Up To 200.00 PSI

1J-048-01 Polyethylene Tubing

1/4 in

0.17 in

Black

Polyethylene Tubing, 0.38 OD, 0.06 Thick, 0.25 ID, Up To 190.00 PSI

1J-074-10 Polyethylene Tubing

3/8 in

1/4 in

Natural

Polyethylene Tubing, 0.31 OD, 0.06 Thick, 0.19 ID, Up To 230.00 PSI

1J-077-10 Polyethylene Tubing

5/16 in

3/16 in

Natural

Polyethylene Tubing, 0.19 OD, 0.03 Thick, 0.13 ID, Up To 200.00 PSI

A43184 Polyethylene Tubing

0.12 in

Natural

FW BLK PE 3/8 X 1/4 X 100 FT BAG

1J-074-01

3/8 in

1/4 in

Black

FW NAT PE 1/2 X 3/8 100 FT BAG

1J-076-10

1/2 in

0.38 in

Natural

FW NAT PE 5/32(4MM) X .106(2.7MM) X 100 FT BAG

1J-189-10

0.11 in

Natural

Product Questions & Answers (1)

Question by: Johnny M on Apr 25, 2025, 2:30 PM
got a tight little run on a panel, how sharp can i bend this tubing without kinking it?
Answer by: Customer Support on Apr 27, 2025, 8:06 AM
For tight routing, the minimum bend radius is 0.5 inches. Staying at or above that bend radius helps keep the tube from flattening out and also reduces stress at the bend.
