main product photo

Skip to the beginning of the images gallery

PRV2-16 Series Pilot-Operated Pressure Reducing (Relieving) Cartridge Valves, Up To 40 GPM & 5000 PSI

Description & Features

Application	This valve is normally open, allowing flow from port 2 to port 1. Port 3 is a drain and must be vented back to reservoir. Once the pressure setting is reached at port 1, the spool shifts to restrict the inlet flow at port 2. This regulates the pressure at port 1. If pressure at port 1 exceeds the predetermined setting of the valve, the spool will shift further and relieve excess pressure through port 3.
Cartridge	Model PRV2-16*, sold separately.
Features	The PRV2-16 is a pilot operated, spool type screw-in cartridge pressure reducing/relieving valve, and requires a machined cavity or housing for installation.
Flow Rating	40 GPM
Housing	Cavity size C-16-3, sold separately, see
Pressure Rating	5000 PSI All ports (CAUTION: Pressures over 3000 PSI require steel housing).
Recommended Filtration	ISO 4406 Cleanliness Level 18/16/13 or cleaner.
Temperature Range	-40°F to 248°F

Products

Model Number	Part Number	Adjustment Style	Cracking Pressure (psi)	Pressure Setting	Housing	Seal Material	Price	Action
PRV2 16 S 0 60 PRV2-16 Series Cartridge Valve	566376	Screw	1000-6000	3500	None	Buna-N

Product Questions & Answers (1)

Question by: Cindy S on Sep 29, 2025, 4:47 PM

What size cavity do I need for this valve?

Answer by: Customer Support on Oct 1, 2025, 6:07 AM

You'll need a cavity size C-16-3 housing for this valve. It's sold separately, though.
