PT240 Polyethylene Tubing, Natural, 0.38 Inch OD, 0.06 Inch Wall Thickness, Up To 135.00 PSI

Description & Features

The natural PT240 polyethylene tubing constructed from durable polyethylene is engineered for a range of industrial and agricultural uses. Its abrasion-resistant properties ensure reliable performance with liquids and gases. Extruded with a robust composition the tubing has a wall thickness of 0.06 inches and offers a minimum bend radius of 1.5 inches. It operates efficiently within a temperature range of -40deg;F to 135deg;F and withstands a maximum working pressure of 135 PSI. Reinforced with UV-stabilized materials it provides excellent durability during prolonged outdoor exposure. The tubing adheres to 21CFR177.1520 regulations making it safe for food contact applications. Available in an array of colors including black yellow orange blue red and green it caters to diverse application requirements. This polyethylene tubing has conductive properties and features an ink jet lay line style for easy identification. Compatible with fittings such as Polylinereg; Brass Push>Connectreg; and Molded Compression it ensures seamless integration.

Supplier Part Number: PT24006NA-200R

MPN: EAR99

Specifications

Abrasion Resistance
28
Application
Liquid and gas.
Color
Natural
Conductivity
30
Construction
Extruded
Cover Material
Polyethelene
Dash Size
-6
Brand
Danfoss (IGS)
Brand
Aeroquip
Pack Size
1.00
UOM
FT
Lay Line Style
Ink Jet
Maximum Working Pressure
135
Minimum Bend Radius
1.50
Minimum Bend Radius
1.5
Minimum Working Temperature
-40
Package Qty.
200
Reinforcement Material
UV Stabilized
Supplier Part Number
PT24006NA-200R
Tube Material
Polyethylene
Tube O.D.
0.38
Tube O.D.
0.375
Wall Thickness
0.06
Alternate Part Numbers
Alternate Part Number C1KN13, Alternate Part Number MI-08751844, Alternate Part Number MINO-00015X15251, Alternate Part Number MINO-00925X00156, Alternate Part Number MINO-00925X91006
Product Weight
0.03 lbs

Similar Products

Model Number Tube O.D. Wall Thickness Color Maximum Working Pressure Burst Pressure Minimum Bend Radius Package Qty. Price Action
PT240 Polyethylene Tubing, Natural, 0.25 Inch OD, 0.06 Inch Wall Thickness, Up To 200.00 PSI

PT24004NA-500R PT240 Polyethylene Tubing

0.25

0.062

Natural

200

0.75

500

Product Questions & Answers (3)

Question by: Rick C on Jul 4, 2025, 10:58 AM
got a tight turn to make on a little run, how sharp can i bend this PT240 tubing without it kinking up?
Answer by: Customer Support on Jul 6, 2025, 8:35 AM
For this size, the minimum bend radius is 1.5 inches. Keeping the bend at or above that radius helps it hold its shape and avoid kinking.
Question by: Danny W on Nov 20, 2025, 6:03 PM
Can this tubing handle being outside in the sun?
Answer by: Customer Support on Nov 22, 2025, 5:04 PM
Yes it can this polyethylene tubing is reinforced with UV-stabilized materials, so it holds up well to prolonged outdoor exposure.
Question by: Lyle B on Aug 14, 2025, 9:28 AM
Does this tubing hold up outside year-round, or does the sun break it down after a while?
Answer by: Customer Support on Aug 16, 2025, 6:19 AM
UV stabilization is built into the material, so extended outdoor exposure is part of what it's made for. The natural off-white color does contain UV stabilizer, and the temperature range runs from -40°F all the way up to 135°F, which covers most outdoor conditions across the seasons. At 135 PSI max working pressure, it holds its own in demanding setups too.
