main product photo

RH Series Center Hole Single-Acting Cylinder, 30 Ton, Inch Rod, Inch Stroke

Ask A Question

Description & Features

Designed for applications requiring a hollow-center configuration, the RH Series Center Hole Single-Acting Cylinder, 30 Ton, Inch Rod, Inch Stroke delivers 30 tons of capacity with a 6.34 sq in effective area and a 2-1/2 inch stroke. The center hole diameter measures 1.297 inches, making it well-suited for bolt tensioning and other through-hole force applications. Extended height is 8.75 inches.

The cylinder body features a corrosion-resistant standpipe with Power Tech treatment and a threaded collar, consistent with the 30-ton single-acting models in the Rh Series lineup. Interchangeable piston head inserts support versatility across multiple setups. This cylinder is furnished with a 9796 3/8" NPT female half coupler and is rated to withstand full dead-end loads. Manufactured under the Hydraulic Tech USA LLC (Spx) brand.

SKU: RH302

Supplier Part Number (MPN): RH302

Alternate Part Numbers: C1JQ58, MI-02065776, MINO-00630X11327

Specifications

Capacity (tons)
30
Cylinder Effective Area (sq in)
6.34
Brand
HYDRAULIC TECH USA LLC(SPX)
Brand
Hydraulic Tech USA
Pack Size
1.00
UOM
EA
Extended Height
8.75
Hole Dia.
1.30
Alternate Part Numbers
Alternate Part Number C1JQ58, Alternate Part Number MI-02065776, Alternate Part Number MINO-00630X11327
Supplier Part Number
RH302
Product Weight
25.60 lbs

Similar Products

Model Number Capacity (tons) Stroke Oil Capacity Retracted Height Extended Height Thread 1 Piston Rod Diameter H Hole Dia. Thread 2 Cylinder Effective Area (sq in) Price Action
RH Series Center Hole Single-Acting Cylinder, 10 Ton, Inch Rod, Inch Stroke

RH102 RH Series Single-Acting Cylinder

10

7.813

0.766

2.21

RH Series Center Hole Single-Acting Cylinder, 12 Ton, Inch Rod, Inch Stroke

RH121 RH Series Single-Acting Cylinder

12

6.438

0.797

2.76

RH Series Center Hole Single-Acting Cylinder, 12 Ton, Inch Rod, Inch Stroke

RH123 RH Series Single-Acting Cylinder

12

10.25

0.8125

2.76

RH Series Center Hole Single-Acting Cylinder, 20 Ton, Inch Rod, Inch Stroke

RH202 RH Series Single-Acting Cylinder

20

8.125

1.078

4.72

RH Series Center Hole Single-Acting Cylinder, 20 Ton, Inch Rod, Inch Stroke

RH203 RH Series Single-Acting Cylinder

20

9.063

1.047

3.92

RH Series Center Hole Single-Acting Cylinder, 30 Ton, Inch Rod, Inch Stroke

RH302 RH Series Single-Acting Cylinder

30

8.75

1.297

6.34

RH Series Center Hole Single-Acting Cylinder, 30 Ton, Inch Rod, Inch Stroke

RH306 RH Series Single-Acting Cylinder

30

15.75

1.281

6.34

RH Series Center Hole Single-Acting Cylinder, 60 Ton, Inch Rod, Inch Stroke

RH603 RH Series Single-Acting Cylinder

60

12.25

2.125

12.31

Product Questions & Answers (2)

Question by: Cheryl G on Jun 11, 2025, 6:34 PM
what exactly is the center hole for on this cylinder, and how big is it? got a bolt tensioning job coming up and tryin to figure out if this'll work
Answer by: Customer Support on Jun 13, 2025, 9:35 AM
The hollow center runs 1.297 inches in diameter straight through the cylinder. That opening lets you slip a bolt, anchor rod, or cable through while the cylinder applies force around it, which is exactly the setup you need for bolt tensioning work. It also handles pulling on cables, forcing screws, and similar through-hole applications where the load path runs down the middle.
Question by: Chad J on Mar 13, 2026, 4:09 PM
got a job pulling on anchor bolts. what size is the hole through the middle on this RH302?
Answer by: Customer Support on Mar 15, 2026, 6:38 AM
For through-bolt and tensioning work, the center hole diameter on the RH302 is 1.297 inches, so your bolt, cable, or forcing screw needs to fit through that opening.
