RV5-10 Series Pilot-Operated Spool Type Relief Cartridge Valves, Up To 5000 PSI & 80 GPM

Description & Features

Cartridge	Model RV5-10-*, sold separately.
Features	Cartridge style (Requires a machined cavity or housing for installation). Smooth and quiet. Continuous duty.
Housing	Cavity size C-10-2, sold separately, see
Maximum Flow Rate	30 GPM.
Maximum Operating Pressure	5000 PSI (CAUTION: Pressures over 3000 PSI require steel housing).

Products

Model Number	Part Number	Adjustable Range	Adjustment Style	Housing	Seal Material
RV5-10-S-0-20/12 RV5-10 Series Cartridge Valve	02-164222	100-2000 (Set at 1200)	Screw	None	Buna-N
RV5-10-S-0-35/14.5 RV5-10 Series Cartridge Valve	02-164723	250-3500 (Set at 1450)	Screw	None	Buna-N
RV5-10-S-0-50/ RV5-10 Series Cartridge Valve	565572	500-5000	Screw	None	Buna-N
RV5-10-S-0-35/ RV5-10 Series Cartridge Valve	566246	250-3500	Screw	None	Buna-N
RV5-10-F-0-35/30 RV5-10 Series Cartridge Valve	02-163944	250-3500 (Set at 3000)	Factory set	None	Buna-N
RV5-10-I-0-35/30 RV5-10 Series Cartridge Valve	02-164733	250-3500 (Set at 3000)	Internal	None	Buna-N
RV5-10-S-0-35/14 RV5-10 Series Cartridge Valve	02-180537	250-3500 (Set at 1400)	Screw	None	Buna-N

Product Questions & Answers (1)

Question by: Donna A on Mar 28, 2026, 9:20 PM

Will this relief valve work okay in a hydraulic system that runs pretty much non-stop all day?

Answer by: Customer Support on Mar 30, 2026, 6:05 AM

These RV5-10 series valves are indeed designed for continuous duty in demanding industrial applications. So, yes, they should hold up just fine for systems running constantly.
