SD25 Series Walvoil SD25 Motor Spool TYPE 2IM

Description & Features

Designed for both open and closed center hydraulic systems, the Walvoil SD25 Motor Spool TYPE 2IM is a robust and versatile component ideal for demanding industrial applications. This sectional valve supports configurations from 1 to 12 sections and offers a maximum operating pressure of 4600 PSI in parallel circuits. It features a main pressure relief valve and load check valve on every work section, ensuring reliable performance.

The SD25 Motor Spool offers a flow rating of 63 GPM and accommodates fluid temperatures ranging from -4°F to 176°F with standard Buna-N seals. Its compact design allows for easy integration into existing systems, and it supports both parallel or series circuits, with optional power beyond ports for enhanced flexibility. Additionally, it can be controlled manually, pneumatically, hydraulically, electro-hydraulically, or via cable, catering to a wide range of operational needs.

SKU: 3CU2725420

Supplier Part Number (MPN): 3CU2725420

Alternate Part Numbers: C1HS92

Specifications

Brand Walvoil Fluid Power Corp.	Brand Walvoil Fluid Power	Pack Size 1.00	UOM EA	Key (3)	Supplier Part Number 3CU2725420	Alternate Part Numbers Alternate Part Number C1HS92	Product Weight 1.62 lbs

Similar Products

Model Number	Key	Product Description
3CU2710420 SD25 Series Valve Work Section	(2)	WALVOIL SD25 CYLINDER SPOOL TYPE 1IM.
3CU2725100 SD25 Series Valve Work Section	(2)	WALVOIL SD25 MOTOR SPOOL TYPE 2.
3CU2725420 SD25 Series Valve Work Section	(3)	WALVOIL SD25 MOTOR SPOOL TYPE 2IM.
5IDR225700 SD25 Series Valve Work Section	(3)	WALVOIL SD25 8IM-SAE REMOTE HYDRAULIC KI.
5V11120000 SD25 Series Valve Work Section	(3)	WALVOIL SD25 -11 3 POS DETENT KIT.

Product Questions & Answers (2)

Question by: Hank H on May 28, 2025, 11:05 AM

got a SD25 valve stack already, is this TYPE 2IM motor spool the interchangeable kind or am i stuck with one setup

Answer by: Customer Support on May 30, 2025, 6:47 AM

With the SD25 Series, the working sections use interchangeable spools, and the TYPE 2IM motor spool is one of those spool options for that valve family.

Question by: Harvey R on Aug 20, 2025, 1:33 PM

Will this section work with a closed center system, or is it just for open center setups?

Answer by: Customer Support on Aug 21, 2025, 8:32 PM

This SD25 series valve section is designed for both open and closed center hydraulic systems, giving you some flexibility in your setup.
