High Performance Stainless Steel Braided Brake Hose, Black, 0.25 Inch OD, 0.13 Inch ID, Up To 3000.00 PSI

Ask A Question

Description & Features

Engineered for demanding environments this black 0.25 inch OD 0.13 inch ID hose ensures reliability under pressures up to 3000 PSI. Designed with a smooth bore PTFE tube and a 304 stainless steel 4-wire braid reinforcement this hose offers optimal strength and flexibility.

Featuring a PVC jacket construction it provides superior resistance to wear and abrasion. The minimum bend radius is 2 inches making it suitable for tight installation spaces while maintaining functionality.

The High Performance Stainless Steel Braided Brake Hose Black 0.25 Inch OD 0.13 Inch ID Up To 3000.00 PSI is ideal for hydraulic brake applications in various industrial settings. This hose is compatible with BrakeQuip crimp fittings ensuring secure and leak-free connections.

With an operating temperature range from -100deg;F to 500deg;F and a burst pressure of 12000 PSI this product is built to withstand extreme conditions. It is classified under the lsquo;Special Application Hosersquo; category providing robust performance for professional use.

Brand: Brakequip LLC

Supplier Part Number: BQ303BK

MPN: BQ303BK

Catalog Number: C1LZ11

Specifications

Cover Material
PVC
For Use With
DOT 3, 4, 5 (Silicone-Based) and 5.1 Brake Fluids
grp Construction
PVC Jacket, 304 Stainless 4-Wire Braid, Thickness 0, 008 in Reinforcement, PTFE Smooth Bore Tube
Hose Color
Smoke
Hose Type
Jacketed Braided Air Brake Hose
Inside Diameter
0.12 in
Reinforcement
4-Wire Braid
Tube Material
Stainless Steel

Product Questions & Answers (1)

Sign In Hover me Please sign in to submit a question
Question by: Larry M on May 19, 2025, 8:02 AM
Running brake lines on a custom build and need something that'll hold up to heat and pressure without giving me fits. This hose rated for anything serious?
Answer by: Customer Support on May 20, 2025, 3:26 PM
Rated to 3000 PSI operating pressure with a burst threshold of 12,000 PSI, so it's got plenty of headroom for hydraulic brake systems. The PTFE smooth bore inner tube and 304 stainless 4-wire braid reinforcement handle both pressure and heat well. Temperature range runs from -100°F all the way up to 500°F, so heat soak from engines or brakes cycling hard isn't going to be a problem.
