TBC Series Stainless Steel T-Bolt Band Clamp, 0.75 Inch Width, 4.53 To 4.84 Inch Diameter

Ask A Question

Description & Features

The TBC Series Stainless Steel T-Bolt Band Clamp 0.75 Inch Width 4.53 To 4.84 Inch Diameter is designed for industrial applications requiring reliable and secure fastening solutions.

This versatile clamp from Dixon Valve & Co. offers an adjustable diameter range from 4.5313 to 4.8438 inches. Constructed with a 301 stainless steel band that is 0.025 inches thick it ensures durability and resistance to corrosion.

The carbon steel bolt equipped with a self-locking nut enhances security and stability. Its 0.75-inch width allows for effective pressure distribution crucial for maintaining a firm grip under challenging conditions.

With a maximum recommended torque of 70 in. lbs. the hexagon T-bolt tightening method provides a reliable fit essential for maintaining the integrity of the connection.

Engineered to meet demanding industrial requirements the clamp's materials and construction guarantee consistent performance and longevity.

MPN: C1DM19

Supplier Part Number: TBC475

Specifications

Brand
Dixon Valve & Co
Brand
Dixon Valve & Co
Pack Size
1.00
UOM
EA
Maximum Diameter
4.84
Minimum Diameter
4.53
Supplier Part Number
TBC475
Product Weight
0.17 lbs
Alternate Part Numbers
Alternate Part Number 03740201120, Alternate Part Number 30050-0475, Alternate Part Number 30050-0475-051, Alternate Part Number 300500475051, Alternate Part Number C1DM19

Similar Products

Model Number Width (in) Minimum Diameter Maximum Diameter Price Action
TBC Series Stainless Steel T-Bolt Band Clamp, 0.75 Inch Width, 1.28 To 1.59 Inch Diameter

TBC150 Stainless T-Bolt Band Clamp

0.75

1.2813

1.5938

TBC Series Stainless Steel T-Bolt Band Clamp, 0.75 Inch Width, 1.53 To 1.84 Inch Diameter

TBC175 Stainless T-Bolt Band Clamp

0.75

1.5313

1.8438

TBC Series Stainless Steel T-Bolt Band Clamp, 0.75 Inch Width, 1.66 To 1.97 Inch Diameter

TBC188 Stainless T-Bolt Band Clamp

0.75

1.6563

1.9688

TBC Series Stainless Steel T-Bolt Band Clamp, 0.75 Inch Width, 1.78 To 2.09 Inch Diameter

TBC200 Stainless T-Bolt Band Clamp

0.75

1.7813

2.0938

TBC Series Stainless Steel T-Bolt Band Clamp, 0.75 Inch Width, 2.28 To 2.59 Inch Diameter

TBC250 Stainless T-Bolt Band Clamp

0.75

2.2813

2.5938

TBC Series Stainless Steel T-Bolt Band Clamp, 0.75 Inch Width, 2.91 To 3.22 Inch Diameter

TBC312 Stainless T-Bolt Band Clamp

0.75

2.9063

3.2188

TBC Series Stainless Steel T-Bolt Band Clamp, 0.75 Inch Width, 1.19 To 1.44 Inch Diameter

TBC131 Stainless T-Bolt Band Clamp

0.75

1.1875

1.4375

TBC Series Stainless Steel T-Bolt Band Clamp, 0.75 Inch Width, 2.03 To 2.34 Inch Diameter

TBC225 Stainless T-Bolt Band Clamp

0.75

2.0313

2.3438

TBC Series Stainless Steel T-Bolt Band Clamp, 0.75 Inch Width, 2.16 To 2.47 Inch Diameter

TBC238 Stainless T-Bolt Band Clamp

0.75

2.1563

2.4688

TBC Series Stainless Steel T-Bolt Band Clamp, 0.75 Inch Width, 2.34 To 2.66 Inch Diameter

TBC256 Stainless T-Bolt Band Clamp

0.75

2.3438

2.6563

TBC Series Stainless Steel T-Bolt Band Clamp, 0.75 Inch Width, 2.41 To 2.72 Inch Diameter

TBC263 Stainless T-Bolt Band Clamp

0.75

2.4063

2.7188

TBC Series Stainless Steel T-Bolt Band Clamp, 0.75 Inch Width, 2.53 To 2.84 Inch Diameter

TBC275 Stainless T-Bolt Band Clamp

0.75

2.5313

2.8438

TBC Series Stainless Steel T-Bolt Band Clamp, 0.75 Inch Width, 2.66 To 2.97 Inch Diameter

TBC288 Stainless T-Bolt Band Clamp

0.75

2.6563

2.9688

TBC Series Stainless Steel T-Bolt Band Clamp, 0.75 Inch Width, 2.78 To 3.09 Inch Diameter

TBC300 Stainless T-Bolt Band Clamp

0.75

2.7813

3.0938

TBC Series Stainless Steel T-Bolt Band Clamp, 0.75 Inch Width, 3.03 To 3.34 Inch Diameter

TBC325 Stainless T-Bolt Band Clamp

0.75

3.0313

3.3438

TBC Series Stainless Steel T-Bolt Band Clamp, 0.75 Inch Width, 3.28 To 3.59 Inch Diameter

TBC350 Stainless T-Bolt Band Clamp

0.75

3.2813

3.5938

TBC Series Stainless Steel T-Bolt Band Clamp, 0.75 Inch Width, 3.53 To 3.84 Inch Diameter

TBC375 Stainless T-Bolt Band Clamp

0.75

3.5313

3.8438

TBC Series Stainless Steel T-Bolt Band Clamp, 0.75 Inch Width, 3.78 To 4.09 Inch Diameter

TBC400 Stainless T-Bolt Band Clamp

0.75

3.7813

4.0938

TBC Series Stainless Steel T-Bolt Band Clamp, 0.75 Inch Width, 4.03 To 4.34 Inch Diameter

TBC425 Stainless T-Bolt Band Clamp

0.75

4.0313

4.3438

TBC Series Stainless Steel T-Bolt Band Clamp, 0.75 Inch Width, 4.28 To 4.59 Inch Diameter

TBC450 Stainless T-Bolt Band Clamp

0.75

4.2813

4.5938

TBC Series Stainless Steel T-Bolt Band Clamp, 0.75 Inch Width, 4.53 To 4.84 Inch Diameter

TBC475 Stainless T-Bolt Band Clamp

0.75

4.5313

4.8438

TBC Series Stainless Steel T-Bolt Band Clamp, 0.75 Inch Width, 4.78 To 5.06 Inch Diameter

TBC500 Stainless T-Bolt Band Clamp

0.75

4.7813

5.0625

TBC Series Stainless Steel T-Bolt Band Clamp, 0.75 Inch Width, 5.28 To 5.59 Inch Diameter

TBC550 Stainless T-Bolt Band Clamp

0.75

5.2813

5.5938

Product Questions & Answers (3)

Question by: Dale F on Aug 25, 2025, 4:51 PM
What's the torque spec on the bolt for this clamp, and what size wrench do I need to tighten it down?
Answer by: Customer Support on Aug 27, 2025, 7:22 AM
Max recommended torque is 70 in. lbs., which is pretty modest and easy to hit without a torque wrench if you've got some feel for it. The bolt uses a hex T-bolt design, so a standard hex socket or wrench will do the job. Just don't crank past 70 in. lbs. or you risk distorting the band or stripping the nut.
Question by: Stan M on Apr 6, 2026, 11:36 AM
need a clamp for a hose that measures right around 4.7 inches, will this one actually tighten down enough?
Answer by: Customer Support on Apr 8, 2026, 6:29 AM
Fit comes down to the clamp’s adjustment range. This T-bolt clamp covers 4.5313 inches minimum up to 4.8438 inches maximum diameter, so a hose or connection around 4.7 inches falls inside that window.
Question by: Phil R on Apr 17, 2025, 7:45 PM
What size range will this clamp fit, exactly? Just want to make sure it'll work for my setup.
Answer by: Customer Support on Apr 19, 2025, 1:34 PM
The clamp is designed to fit diameters from 4.5313 inches up to 4.8438 inches. This should give you a secure fit within that range.
