Steel Adapter, 1-5/8-12 Female JIC 37 deg Flare Swivel To 1-5/16-12 Male JIC 37 deg Flare, Straight

Ask A Question

Description & Features

Part of the Danfoss Power Solutions (Aeroquip) 221501 Series, this fitting connects a 1-5/8-12 female JIC 37° flare swivel end to a 1-5/16-12 male JIC 37° flare end in a straight configuration. Both ends use SAE 37° flare seating, providing a reliable metal-to-metal seal suited for high-pressure hydraulic lines. The reducer design accommodates two different thread sizes within a single inline adapter, eliminating the need for additional fittings when transitioning between line sizes.

Constructed from steel, this adapter carries a minimum working temperature rating of -65°F, making it suitable for demanding low-temperature environments. No thread sealant is required given the flare-type sealing method. The catalog reference for this part is C1BC68, and it is classified under EAR99 for export purposes. The Steel Adapter, 1-5/8-12 Female JIC 37 deg Flare Swivel To 1-5/16-12 Male JIC 37 deg Flare, Straight is a standard component used across a range of industrial hydraulic assemblies.

SKU: 221501-20-16S

Supplier Part Number (MPN): 221501-20-16S

Alternate Part Numbers: C1BC68, MI-00315853, MINO-00015F63947

Specifications

A
1.52
Alternate Part Numbers
Alternate Part Number C1BC68, Alternate Part Number MI-00315853, Alternate Part Number MINO-00015F63947
Application
Other
Brand
Danfoss Power Solutions (II LLC Aeroquip)
Brand
Aeroquip
Pack Size
1.00
UOM
EA
End Gender 1
13553
End Gender 2
13556
End Size 2
1
End Type 1
SAE 37
End Type 2
SAE 37
Minimum Working Temperature
-65
Supplier Part Number
221501-20-16S
Thread 1
1-5/8-12
Thread 2
1-5/16-12
Thread Sealant
No
Tube O.D.
1
Tube O.D.
1
Product Weight
0.79 lbs

Related Documents

Similar Products

Model Number Tube O.D. Thread 1 Thread 2 A Price Action
Steel Adapter, 1-1/16-12 Female JIC 37 deg Flare Swivel To 9/16-18 Male JIC 37 deg Flare, Straight

221501-12-6S Steel Female To Male JIC Adapter

0.38

1-1/16-12

9/16-18

1.09

Steel Adapter, 1-1/16-12 Female JIC 37 deg Flare Swivel To 3/4-16 Male JIC 37 deg Flare, Straight

221501-12-8S Steel Female To Male JIC Adapter

0.5

1-1/16-12

3/4-16

1.19

Steel Adapter, 1-5/16-12 Female JIC 37 deg Flare Swivel To 1-1/16-12 Male JIC 37 deg Flare, Straight

221501-16-12S Steel Female To Male JIC Adapter

0.75

1-5/16-12

1-1/16-12

1.47

Steel Adapter, 1-5/16-12 Female JIC 37 deg Flare Swivel To 9/16-18 Male JIC 37 deg Flare, Straight

221501-16-6S Steel Female To Male JIC Adapter

0.38

1-5/16-12

9/16-18

1.16

Steel Adapter, 1-5/8-12 Female JIC 37 deg Flare Swivel To 1-5/16-12 Male JIC 37 deg Flare, Straight

221501-20-16S Steel Female To Male JIC Adapter

1

1-5/8-12

1-5/16-12

1.52

Steel Adapter, 3/4-16 Female JIC 37 deg Flare Swivel To 9/16-18 Male JIC 37 deg Flare, Straight

221501-8-6S Steel Female To Male JIC Adapter

0.38

3/4-16

9/16-18

1

Steel Adapter, 7/8-14 Female JIC 37 deg Flare Swivel To 9/16-18 Male JIC 37 deg Flare, Straight

221501-10-6S Steel Female To Male JIC Adapter

0.38

7/8-14

9/16-18

1.03

Steel Adapter, 1-5/16-12 Female JIC 37 deg Flare Swivel To 7/8-14 Male JIC 37 deg Flare, Straight

221501-16-10S Steel Female To Male JIC Adapter

0.63

1-5/16-12

7/8-14

1.36

Steel Adapter, 1-5/16-12 Female JIC 37 deg Flare Swivel To 3/4-16 Male JIC 37 deg Flare, Straight

221501-16-8S Steel Female To Male JIC Adapter

0.5

1-5/16-12

3/4-16

1.26

Steel Adapter, 9/16-18 Female JIC 37 deg Flare Swivel To 7/16-20 Male JIC 37 deg Flare, Straight

221501-6-4S Steel Female To Male JIC Adapter

0.25

9/16-18

7/16-20

0.97

Steel Adapter, 3/4-16 Female JIC 37 deg Flare Swivel To 7/16-20 Male JIC 37 deg Flare, Straight

221501-8-4S Steel Female To Male JIC Adapter

0.25

3/4-16

7/16-20

1

Steel Adapter, 9/16-18 Female JIC 37 deg Flare Swivel To 9/16-18 Male JIC 37 deg Flare, Straight

6504-0606 Steel Female To Male JIC Adapter

0.38

9/16-18

9/16-18

1.59

Steel Adapter, 7/8-14 Female JIC 37 deg Flare Swivel To 7/8-14 Male JIC 37 deg Flare, Straight

6504-1010 Steel Female To Male JIC Adapter

0.63

7/8-14

7/8-14

2.17

Product Questions & Answers (2)

Question by: Norm R on Apr 27, 2025, 4:50 PM
i’ve got a hose end that’s 1-5/8-12 female JIC swivel, will this adapter step it down to a 1-5/16-12 male JIC and stay straight?
Answer by: Customer Support on Apr 29, 2025, 4:37 PM
For stepping down JIC sizes, this part is a straight steel reducer adapter with a 1-5/8-12 female JIC 37 degree flare swivel on one end and a 1-5/16-12 male JIC 37 degree flare on the other.
Question by: Stan R on Oct 20, 2025, 10:35 AM
Hey, I'm trying to replace an adapter on my Danfoss system. Is this the right one for a 1-5/8-12 female JIC to 1-5/16-12 male JIC connection?
Answer by: Customer Support on Oct 22, 2025, 6:11 AM
This Eaton Aeroquip adapter is indeed designed for that exact connection type. It’s a straight steel adapter going from a 1-5/8-12 Female JIC 37 deg Flare Swivel to a 1-5/16-12 Male JIC 37 deg Flare. Double-check those sizes, though, just to be sure.
