main product photo

Steel Adapter, 1-5/16-12 Male JIC 37 deg Flare To 1-5/16-12 Male JIC 37 deg Flare, 45 deg Elbow Bulkhead

Ask A Question

Description & Features

The Eaton Aeroquip Steel Adapter is designed for high-performance applications requiring reliable hydraulic connections. Featuring a 1-5/16-12 Male JIC 37-degree flare to 1-5/16-12 Male JIC 37-degree flare configuration, this adapter is engineered for seamless integration into systems where a 45-degree elbow bulkhead is essential. Constructed from durable steel, it ensures robust performance in demanding environments.

Ideal for industries such as marine/military, chemical processing, pulp and paper, food and beverage, and off-shore drilling, this adapter supports fluid compatibility in challenging conditions. The Eaton Aeroquip brand is synonymous with quality, ensuring this adapter meets rigorous industry standards. With an Eaton catalog number of C1HH77, this component is a reliable choice for professionals seeking dependable hydraulic solutions.

SKU: 2042-16-16S

Supplier Part Number (MPN): 2042-16-16S

Alternate Part Numbers: C1HH77

Specifications

a Dimensions
2.58 in
b Dimensions
1.47 in
Connection Size 1
1 in
Connection Size 2
1 in
Connection Type
Male Bulkhead, Male JIC
Connection Type 1
Male SAE 37 deg JIC Flare
Connection Type 2
Male Bulkhead
Dimension Standards
SAE 070801/J514
Drop Dimensions
1.47 in
Finish
Dura-Kote™
Fitting Type
45 deg Elbow
Material
Steel
Material Construction
Carbon Steel
Operating Temperature
-65
Series
2042 Series
Thread Size
1-5/16-12

Product Questions & Answers (2)

Sign In Hover me Please sign in to submit a question
Question by: Wayne R on Feb 10, 2026, 9:17 AM
Been looking for a bulkhead elbow to tie into a line on our offshore drilling rig setup. This the right kind of fitting for that application?
Answer by: Customer Support on Feb 11, 2026, 9:37 PM
Offshore drilling is one of the listed applications for this fitting, so you're on the right track. It's a 45 degree elbow bulkhead adapter with 1-5/16-12 Male JIC 37 degree flare on both ends, part of the Eaton Aeroquip 2042 Series. The bulkhead design lets it pass through a panel or wall, and the 45 degree angle helps route lines where a straight adapter just won't clear. Both ends are the same thread and flare spec, so your JIC connections on each side need to match that 1-5/16-12 sizing.
Question by: Rick H on Oct 23, 2025, 4:58 PM
So this is a 45 degree angle, right? Just want to make sure before I order.
Answer by: Customer Support on Oct 25, 2025, 12:17 PM
That's correct. This adapter features a 45-degree elbow design.
