main product photo

Steel Adapter, 7/16-20 Male JIC 37 deg Flare To 7/16-20 Male JIC 37 deg Flare, 45 deg Elbow Bulkhead

Ask A Question

Description & Features

Engineered for demanding applications, the Steel Adapter, 7/16-20 Male JIC 37 deg Flare To 7/16-20 Male JIC 37 deg Flare, 45 deg Elbow Bulkhead is a versatile component designed to ensure robust connections in hydraulic systems. Featuring a 45-degree elbow design, this adapter is ideal for installations where space is limited, providing flexibility without compromising on performance. The 7/16-20 male JIC 37-degree flare connections offer reliable sealing, perfect for high-pressure environments.

Crafted by Eaton Aeroquip, this adapter is suitable for diverse applications, including marine and military use, chemical processing, and off-shore drilling. Its compatibility with various fluids is backed by comprehensive documentation, ensuring long-lasting performance across different industrial settings. With attributes such as a length of 1.55 inches and a width of 0.73 inches, this component meets the precise requirements of complex hydraulic systems.

SKU: 2042-4-4S

Supplier Part Number (MPN): 2042-4-4S

Alternate Part Numbers: C1AY48, MI-00315400, MINO-00015F63585

Specifications

A
1.55
Alternate Part Numbers
Alternate Part Number C1AY48, Alternate Part Number MI-00315400, Alternate Part Number MINO-00015F63585
Application
Marine/Military, Chemical Processing, Pulp and Paper Industries, Food and Beverage Processing, Off-Shore Drilling
B
0.73
Drop Dimension
0.72
Brand
Danfoss Power Solutions (II LLC Aeroquip)
Brand
Aeroquip
Pack Size
1.00
UOM
EA
End Gender 1
13554
End Gender 2
13556
End Size 1
0.44
End Size 2
0.44
End Type 1
SAE 37
End Type 2
SAE 37
Minimum Working Temperature
-65
Supplier Part Number
2042-4-4S
Thread 1
7/16-20
Thread 2
7/16-20
Thread Sealant
No
Tube O.D.
0.25
Tube O.D.
0.25
Product Weight
0.10 lbs

Related Documents

Similar Products

Model Number Tube O.D. Thread 1 Thread 2 A B Price Action
Steel Adapter, 9/16-18 Male JIC 37 deg Flare To 9/16-18 Male JIC 37 deg Flare, 45 deg Elbow Bulkhead

2042-6-6S Steel Male JIC 45 Elbow Bulkhead

0.38

9/16-18

9/16-18

1.64

0.83

Steel Adapter, 1-1/16-12 Male JIC 37 deg Flare To 1-1/16-12 Male JIC 37 deg Flare, 45 deg Elbow Bulkhead

2042-12-12S Steel Male JIC 45 Elbow Bulkhead

0.75

1-1/16-12

1-1/16-12

2.36

1.41

Steel Adapter, 1-5/16-12 Male JIC 37 deg Flare To 1-5/16-12 Male JIC 37 deg Flare, 45 deg Elbow Bulkhead

2042-16-16S Steel Male JIC 45 Elbow Bulkhead

1

1-5/16-12

1-5/16-12

2.58

1.47

Steel Adapter, 7/16-20 Male JIC 37 deg Flare To 7/16-20 Male JIC 37 deg Flare, 45 deg Elbow Bulkhead

2042-4-4S Steel Male JIC 45 Elbow Bulkhead

0.25

7/16-20

7/16-20

1.55

0.73

Steel Adapter, 3/4-16 Male JIC 37 deg Flare To 3/4-16 Male JIC 37 deg Flare, 45 deg Elbow Bulkhead

2042-8-8S Steel Male JIC 45 Elbow Bulkhead

0.5

3/4-16

3/4-16

2.08

0.98

Steel Adapter, 7/16-20 Male JIC 37 deg Flare To 7/16-20 Male JIC 37 deg Flare, 45 deg Elbow Bulkhead

2702-LN-04-04-FG Steel Male JIC 45 Elbow Bulkhead

0.25

7/16-20

7/16-20

1.53

0.72

Product Questions & Answers (3)

Question by: Bobby W on May 7, 2025, 12:38 PM
Will this here fitting hold up okay if I’m running hydraulic fluid through it on a regular basis?
Answer by: Customer Support on May 9, 2025, 12:05 PM
This adapter is well-suited for hydraulic applications. You'll also want to consult the fluid compatibility document to be sure it’s compatible with the specific fluid you intend to use.
Question by: Chad K on Mar 20, 2026, 1:43 PM
Got a bulkhead fitting situation on a marine hydraulic line and need something that'll make a 45-degree turn without a bunch of extra fittings stacked up. this one work for that?
Answer by: Customer Support on Mar 22, 2026, 11:47 AM
That setup is exactly what this fitting is built around. It's a 45-degree elbow bulkhead configuration with 7/16-20 male JIC 37-degree flare on both ends, so you get the directional change and the bulkhead mount all in one piece. No need to stack a straight bulkhead adapter and a separate elbow. Marine is also one of the listed application environments for this part, so it lines up with what you're working on.
Question by: Phil W on Jul 11, 2025, 5:27 PM
trying to replace an old 45 elbow on a bulkhead, is this one 7/16-20 on both ends and JIC 37 flare?
Answer by: Customer Support on Jul 13, 2025, 6:21 AM
It’s a 45 degree bulkhead elbow adapter with 7/16-20 male JIC 37 degree flare on both sides. That makes it a straight swap when you need male JIC flare to male JIC flare in that same thread size through a bulkhead.
