Steel Adapter, 3/8-18 Male NPT To 9/16-18 Female JIC 37 deg Flare Swivel, Straight

Description & Features

Manufactured from steel, this straight adapter connects a 3/8-18 male NPT thread to a 9/16-18 female JIC 37° flare swivel, making it a practical solution for transitioning between NPT pipe thread and JIC flare fittings in hydraulic lines. The swivel end allows for repositioning during installation without disturbing the sealed connection.

The Steel Adapter, 3/8-18 Male NPT To 9/16-18 Female JIC 37 deg Flare Swivel, Straight is cataloged under Brennan Industries as part of their Pipe to 37° Flare Steel Adapters line. With an overall length of 1.72 inches, it is suited for compact routing situations where space is limited.

Typical applications include hydraulic systems requiring a reliable, leak-free connection between NPT-threaded components and JIC flare assemblies.

SKU: 6505-0606

Supplier Part Number (MPN): 6505-06-06

Specifications

A 1.72	Brand Brennan Industries Inc	Brand Brennan Industries	Pack Size 1.00	UOM EA	Supplier Part Number 6505-06-06	Thread 1 3/8-18	Thread 2 9/16-18	Thread Sealant No	Tube O.D. 0.38	Tube O.D. 0.38	Product Weight 0.11 lbs

Similar Products

Model Number	Tube O.D.	Thread 1	Thread 2	A
2018-12-12S Steel Male NPT To Female JIC Adapter	0.75	3/4-14	1-1/16-12	2.15
2018-16-16S Steel Male NPT To Female JIC Adapter	1	1-11-1/2	1-5/16-12	2.54
2018-4-6S Steel Male NPT To Female JIC Adapter	0.38	1/4-18	9/16-18	1.59
2018-6-8S Steel Male NPT To Female JIC Adapter	0.5	3/8-18	3/4-16	1.74
2018-8-8S Steel Male NPT To Female JIC Adapter	0.5	1/2-14	3/4-16
2018-2-4S Steel Male NPT To Female JIC Adapter	0.25	1/8-27	7/16-20	1.32
2018-20-20S Steel Male NPT To Female JIC Adapter	1.25	1-1/4-11-1/2	1-5/8-12	2.78
2018-6-6S Steel Male NPT To Female JIC Adapter	0.38	3/8-18	9/16-18	1.72
6505-04-05 Steel Male NPT To Female JIC Adapter	0.31	1/4-18	1/2-20	1.41
6505-06-10 Steel Male NPT To Female JIC Adapter	0.63	3/8-18	7/8-14	1.86
6505-08-12 Steel Male NPT To Female JIC Adapter	0.75	1/2-14	1-1/16-12	2.17
6505-12-10 Steel Male NPT To Female JIC Adapter	0.63	3/4-14	7/8-14	1.93
6505-24-24 Steel Male NPT To Female JIC Adapter	1.5	1-1/2-11-1/2	1-7/8-12	2.93
6505-04-04 Steel Male NPT To Female JIC Adapter	0.25	1/4-18	7/16-20	1.45
6505-0606 Steel Male NPT To Female JIC Adapter	0.38	3/8-18	9/16-18	1.72
6505-0810 Steel Male NPT To Female JIC Adapter	0.5	1/2-14	7/8-14	2.28
6505-1216 Steel Male NPT To Female JIC Adapter	1	3/4-14	1-5/16-12	2.4

Product Questions & Answers (1)

Question by: Peggy G on Sep 24, 2025, 8:52 PM

Will this adapter hold up okay in a hydraulic system for a log splitter? Seems like it's made of decent steel.

Answer by: Customer Support on Sep 26, 2025, 6:21 AM

This steel adapter is designed for hydraulic systems requiring a reliable, leak-free connection between NPT-threaded components and JIC flare assemblies, so it should be suitable for log splitter applications.
