Steel Adapter, 1-11-1/2 Male NPT Run To 1-11-1/2 Female NPT Run & Branch, Tee

Ask A Question

Description & Features

Manufactured by SSP Fittings Corp, this 1-11½ NPT tee adapter provides a male run connection on one end and a female run-and-branch configuration on the other, allowing a straight line run to be tapped with a branch connection of the same thread size. Constructed from 316 stainless steel, it is well suited for industrial fluid handling applications where corrosion resistance and strength are priorities. The overall length is 2.34 inches, with matching 1-11½ NPT threads on both connections.

The Steel Adapter, 1-11-1/2 Male NPT Run To 1-11-1/2 Female NPT Run & Branch, Tee carries the SSP Fittings Corp catalog number C1CY39 and is part of the Pipe to Pipe Stainless Steel Adapters product line. It is a practical choice for inline tee configurations in hydraulic and industrial fluid systems where a consistent 1-inch NPT thread size is required throughout.

SKU: HN-1

Supplier Part Number (MPN): 1HN

Alternate Part Numbers: C1CY39, MI-08749966, MINO-00766X98444

Specifications

Connection Size 1
1 in
Connection Size 2
1 in
Connection Type
MNPT
Connection Type 1
MNPT
Connection Type 2
MNPT
Dimension Standards
ANSI/ASME B1.20.1, ANSI/ASME BS 21, SAE J514, JIS B0203
Fitting Type
Nipple
Hex Size
1-3/8 in
Material
Stainless Steel
Material Construction
316 Stainless Steel
Series
HN Series
Thread Sealant
Without Thread Sealant
Thread Size
1-11-1/2

Product Questions & Answers (2)

Sign In Hover me Please sign in to submit a question
Question by: Stan S on Nov 28, 2025, 11:11 AM
what's the thread size on both ends of this tee, and are they the same all the way around including the branch?
Answer by: Customer Support on Nov 29, 2025, 3:48 PM
All three connections on this fitting run 1-11/2 NPT. The male run end, the female run end, and the female branch are all the same size, so you won't be stepping up or down anywhere in the assembly. That keeps things straightforward if you're building out a line that needs a consistent one-inch thread size throughout without mixing reducers into the mix.
Question by: Frank S on Mar 14, 2026, 4:36 PM
got a 1 inch NPT line and need to add a side port, is this tee all the same thread size on every opening?
Answer by: Customer Support on Mar 16, 2026, 8:30 AM
All three connections are 1-11-1/2 NPT. It gives you a male NPT on one end of the run, and female NPT on the other end of the run plus the branch, so you can keep the same 1 inch NPT thread size through the tee.
