Steel SAE 4-Bolt Flange Plug, 0.75 Inch Code 62 Flange, O-Ring Half

Description & Features

Designed for applications requiring robust and reliable sealing this flange plug ensures a secure fit. Constructed from high-quality steel it offers superior durability and longevity.

The 0.75-inch pad size is suitable for various industrial uses providing exceptional performance under demanding conditions. Engineered to meet SAE Code 62 standards this plug maintains integrity even under high pressure.

Its O-ring half design facilitates effective sealing minimizing the risk of leaks. The component is ideal for those seeking dependable flange accessories tailored to rigorous specifications.

Manufactured by Anchor Fluid Power renowned for their precision and quality this plug is an essential part for maintaining optimal functionality in your systems.

MPN: C1ES44

Supplier Part Number: 12FOPX

Specifications

A 1.63	C 1.25	D 0.35	E 0.69	Brand Anchor Fluid Power	Brand Anchor Fluid Power	Pack Size 1.00	UOM EA	Manual Override Option No	Pad Size 0.75	Supplier Part Number 12FOPX	Product Weight 0.30 lbs	Alternate Part Numbers Alternate Part Number C1ES44, Alternate Part Number MI-02753746, Alternate Part Number MINO-00054H27611

Similar Products

Model Number	Pad Size	A	C	D	E
12FOPX Steel SAE Code 62 Flange Plug	0.75	1.63	1.25	0.345	0.687
16FOPX Steel SAE Code 62 Flange Plug	1	1.88	1.5	0.38	0.81
20FOPX Steel SAE Code 62 Flange Plug	1.25	2.125	1	0.405	1.75
24FOPX Steel SAE Code 62 Flange Plug	1.5	2.5	2	0.495	1.187

Product Questions & Answers (3)

Question by: Billy S on Nov 15, 2025, 12:44 PM

So, this is a plug for a flange...how does that O-ring part work?

Answer by: Customer Support on Nov 17, 2025, 7:41 AM

The O-ring half design ensures a tight, effective seal when the plug is installed, minimizing the chance of leaks, even under high pressure.

Question by: Hank G on Apr 26, 2025, 8:50 PM

got a Code 62 flange port that needs capping off on a hydraulic manifold, will this plug fit a 0.75 inch pad size?

Answer by: Customer Support on Apr 28, 2025, 6:19 AM

Yes, the pad size on this plug is 0.75 inch and it's built to SAE Code 62 4-bolt flange standards, so it should drop right into that application. The O-ring half design handles the sealing at the face, which is standard for this style of flange port cap.

Question by: Curt M on May 9, 2025, 8:47 AM

got a 0.75 pad SAE code 62 4-bolt setup, is this the right plug for that?

Answer by: Customer Support on May 11, 2025, 6:34 AM

For a 0.75 inch pad size in an SAE Code 62 4-bolt flange connection, this plug matches that standard and size. It is the O-ring half style, so it is meant to seal with an O-ring at the flange.
