main product photo

SV13-10-C Series 2-Way, 2-Position, Normally Closed Solenoid Cartridge Valve, Housing: None, Coil: Not Included

Ask A Question

Description & Features

Designed for mobile and industrial hydraulic circuits, this screw-in cartridge valve handles up to 5,000 PSI and flows up to 12 GPM through a compact, hardened and ground steel body. In the de-energized state, flow from port 2 to port 1 is blocked, while free flow is permitted from port 1 to port 2. When energized, the pilot poppet lifts off its seat, allowing bidirectional flow. The SV13-10-C Series 2-Way, 2-Position, Normally Closed Solenoid Cartridge Valve fits a C-10-2 cavity and is suited for harvesters, refuse haulers, and a broad range of mobile and industrial hydraulic applications.

Coil and housing are sold separately. The valve uses Buna-N seals, requires ISO 4406 cleanliness level 18/16/13 or cleaner, and operates across a temperature range of -40° to 212°F. Note that pressures exceeding 3,000 PSI require a steel housing or manifold. Internal leakage is rated at 5 drops per minute maximum at 5,000 PSI. The coil is a 10 Series, 29-Watt configuration, also sold separately.

SKU: 02-175805

Supplier Part Number (MPN): 02-175805

Alternate Part Numbers: C1MG12, SV1310C000

Specifications

Application
Harvesters, refuse haulers, mobile and industrial applications
Check Valve
No
Coil
Not Included
Coil Series
10 Series, 29 W
Diode
No
Brand
Danfoss – Hydraulics
Brand
Danfoss Power Solutions
Pack Size
1.00
UOM
EA
Features
350 bar (5000 psi) & 227 L/min (60 USgpm)|Reliable, economical and compact|Hardened and ground steel
Housing
None
Installation Type
Screw-in Cartridge
Manual Override Option
No
Number of Housing Ports
2
Number of Valve Ports
2
Port Type
Cartrige Only
Recommended Filtration Level
18/16/13
Seal Material
Buna-N
Seal Type
Buna-N
Special Features
None
Style
2-Way 2-Position Normally Closed
Supplier Part Number
02-175805
Switch Connector
No
Valve Material
Cartridge only
Product Weight
0.40 lbs
Alternate Part Numbers
Alternate Part Number C1MG12, Alternate Part Number SV1310C000

Related Documents

Similar Products

Model Number Part Number Housing Coil Seal Material Price Action
SV13-10-C Series 2-Way, 2-Position, Normally Closed Solenoid Cartridge Valve, Housing: None, Coil: Not Included

SV13-10-C-0-00 SV13-10-C Series Cartridge Valve

02-175805

None

Not Included

Buna-N

Product Questions & Answers (1)

Question by: Tommy M on Jun 23, 2025, 12:35 PM
trying to hold a load with low leakage, is this the kind of valve for that or is it more of a dump valve deal
Answer by: Customer Support on Jun 24, 2025, 1:45 PM
For low leakage load holding, the SV13-10-C is a good fit since it is a poppet style, normally closed, pilot operated 2-way valve with internal leakage listed at 5 drops per minute max at 5000 PSI. It also gets used as a general purpose diverter or dump valve, so it can cover either role depending on how you plumb ports 1 and 2 in your circuit.
