SV3-10-C Series 2-Way, 2-Position, Normally Closed Solenoid Cartridge Valve, Housing: None, Coil: 12VDC

Ask A Question

Description & Features

The SV3-10-C Series 2-Way 2-Position Normally Closed Solenoid Cartridge Valve by Danfoss Hydraulics is designed for robust industrial applications such as harvesters and refuse haulers. Engineered with a flow rating of 12 GPM and a pressure rating of 3000 PSI it ensures reliable performance under demanding conditions.

Constructed from hardened and ground steel this solenoid valve features a compact design and operates with a 12VDC coil. The valve provides efficient fluid control with minimal internal leakage of less than 5 drops per minute at 210 bar.

Compatible with C-10-2 cavity housing this screw-in cartridge valve is built for durability and longevity. It is suitable for mobile and industrial applications offering a recommended filtration level of ISO 4406 Cleanliness Level 18/16/13 or cleaner. The valve supports a temperature range from -40deg;F to 248deg;F making it versatile for extreme environments.

**Model Number:** SV3-10-C-0-12DG

**Supplier Part Number:** 565657

Specifications

Application
Harvesters, refuse haulers, mobile and industrial applications
Check Valve
No
Coil
12VDC
Coil Series
210 bar
Coil Special Features
None
Diode
No
Brand
Danfoss – Hydraulics
Brand
Danfoss Power Solutions
Pack Size
1.00
UOM
EA
Features
350 bar (5000 psi) & 227 L/min (60 USgpm)|Reliable, economical and compact|Hardened and ground steel
Housing
None
Installation Type
Screw-in Cartridge
Leakage
less than 5 drops/min, max @ 210 bar
Manual Override Option
No
Number of Housing Ports
2
Number of Valve Ports
2
Port Type
Cartrige Only
Recommended Filtration Level
18/16/13
Seal Material
Buna-N
Seal Type
Buna-N
Special Features
None
Style
2-Way 2-Position Normally Closed
Supplier Part Number
565657
Switch Connector
No
Valve Material
Cartridge only
Voltage
12 volt
Voltage Type
12307
Product Weight
0.92 lbs
Alternate Part Numbers
Alternate Part Number C1MZ62, Alternate Part Number MINO-00569X10064, Alternate Part Number SV310C012DG

Related Documents

Similar Products

Model Number Part Number Manual Override Option Housing Coil Seal Material Price Action
SV3-10-C Series 2-Way, 2-Position, Normally Closed Solenoid Cartridge Valve, Housing: None, Coil: Not Included

SV3-10-C-0-00 SV3-10-C Series Cartridge Valve

565536

None

Not Included

Buna-N

SV3-10-C Series 2-Way, 2-Position, Normally Closed Solenoid Cartridge Valve, Housing: None, Coil: 12VDC

SV3-10-C-0-12DG SV3-10-C Series Cartridge Valve

565657

None

12VDC

Buna-N

Product Questions & Answers (2)

Question by: Brett B on Dec 31, 2025, 8:02 PM
Reckon this'll fit in a standard C-10-2 cavity, or am I gonna need somethin' special?
Answer by: Customer Support on Jan 2, 2026, 6:43 AM
This SV3-10-C series valve is indeed compatible with a C-10-2 cavity housing. Just make sure you get the housing separately since it ain't included.
Question by: Gene R on Apr 14, 2025, 9:17 AM
does this valve need a housing included or do i have to buy that separate
Answer by: Customer Support on Apr 15, 2025, 3:18 PM
The cartridge itself ships without a housing. You'll need to source a C-10-2 cavity housing separately before installation. Same goes for the coil if you don't already have one on hand. Both are sold apart from this unit, so make sure you've got those pieces lined up before you go pulling the old valve out.
