main product photo

SV4-10-3 Series 3-Way, 2-Position Solenoid Cartridge Valve, Housing: None, Coil: 115VAC 1/2" NPT conduit

Ask A Question

Description & Features

Designed for mobile and industrial hydraulic circuits, the SV4-10-3 Series 3-Way, 2-Position Solenoid Cartridge Valve is a direct-acting, spool-type screw-in cartridge valve rated to 3,000 PSI with a flow rating of 6 GPM. It installs into a C-10-3 machined cavity or housing, which is sold separately.

In the de-energized state, flow passes from port 1 to port 2 while port 3 is blocked. When energized, flow routes from port 2 to port 3 while port 1 is blocked. The valve operates across a wide temperature range of -40°F to 248°F and is built from hardened and ground steel with Buna-N seals.

Suited for harvesters, refuse haulers, and a broad range of mobile and industrial hydraulic applications. Recommended filtration is ISO 4406 cleanliness level 18/16/13 or cleaner. Manufactured by Eaton Vickers, now under Danfoss Power Solutions.

SKU: 02-167839

Supplier Part Number (MPN): 02-167839

Alternate Part Numbers: C1KH68, HW-859416

Specifications

Application
Harvesters, refuse haulers, mobile and industrial applications
Check Valve
No
Coil
115VAC 1/2" NPT conduit
Diode
No
Brand
Danfoss – Hydraulics
Brand
Danfoss Power Solutions
Pack Size
1.00
UOM
EA
Features
350 bar (5000 psi) & 227 L/min (60 USgpm)|Reliable, economical and compact|Hardened and ground steel
Housing
None
Manual Override Option
No
Seal Material
Buna-N
Supplier Part Number
02-167839
Switch Connector
No
Voltage
115 volt
Product Weight
1.22 lbs
Alternate Part Numbers
Alternate Part Number C1KH68, Alternate Part Number HW-859416, Alternate Part Number MINO-00900X50802

Related Documents

Similar Products

Model Number Part Number Manual Override Option Housing Coil Seal Material Price Action
SV4-10-3 Series 3-Way, 2-Position Solenoid Cartridge Valve, Housing: None, Coil: 115VAC 1/2

SV4-10-3-0-115AP SV4-10-3 Series Cartridge Valve

02-167839

None

115VAC 1/2" NPT conduit

Buna-N

SV4-10-3 Series 3-Way, 2-Position Solenoid Cartridge Valve, Housing: None, Coil: Not Included

SV4-10-3-0-00 SV4-10-3 Series Cartridge Valve

566307

None

Not Included

Buna-N

Product Questions & Answers (1)

Question by: Scott H on Oct 24, 2025, 8:30 PM
what exactly happens when this valve ain't energized, does it just block everything or is flow still moving somewhere?
Answer by: Customer Support on Oct 26, 2025, 3:36 PM
Flow stays active between ports 1 and 2 in the de-energized state, while port 3 stays blocked. Once you energize it, that switches over, port 2 routes to port 3 and port 1 gets blocked. It's a full path swap, not a shutoff, so fluid is always moving through one of those two routes depending on whether the solenoid is pulled in or not.
