main product photo

SV4-10-C Series 2-Way, 2-Position, Normally Closed Solenoid Cartridge Valve, Housing: Aluminum FR 1/4" BSPP, Coil: 230VAC 1/2" NPT conduit

Ask A Question

Description & Features

Designed for direct-acting, spool-type control in hydraulic systems, the SV4-10-C Series 2-Way, 2-Position, Normally Closed Solenoid Cartridge Valve from Eaton Vickers handles flow rates up to 6 GPM at pressures up to 3000 PSI. In the de-energized state, flow is blocked in both directions; energizing the solenoid lifts the spool to permit bidirectional flow.

This configuration ships with an aluminum FR housing ported to 1/4" BSPP and a 230VAC coil with 1/2" NPT conduit connection. Buna-N seals provide reliable performance across a temperature range of -40°F to 248°F. The valve installs into a C-10-2 machined cavity, and recommended system filtration is ISO 4406 cleanliness level 18/16/13 or cleaner. The cartridge, housing, and J Series coil are each sold separately.

SKU: 02-167864

Supplier Part Number (MPN): 02-167864

Alternate Part Numbers: C1MG11

Specifications

Check Valve
No
Coil
230VAC 1/2" NPT conduit
Diode
No
Brand
Danfoss (Power Solutions II LLC)
Brand
Danfoss Power Solutions
Pack Size
1.00
UOM
EA
Housing
Aluminum FR 1/4" BSPP
Manual Override Option
No
Seal Material
Buna-N
Supplier Part Number
02-167864
Switch Connector
No
Product Weight
2.20 lbs
Alternate Part Numbers
Alternate Part Number C1MG11

Related Documents

Similar Products

Model Number Part Number Manual Override Option Housing Coil Seal Material Price Action
SV4-10-C Series 2-Way, 2-Position, Normally Closed Solenoid Cartridge Valve, Housing: Aluminum FR 1/4

SV4-10-C-2G-230AP SV4-10-C Series Cartridge Valve

02-167864

Aluminum FR 1/4" BSPP

230VAC 1/2" NPT conduit

Buna-N

SV4-10-C Series 2-Way, 2-Position, Normally Closed Solenoid Cartridge Valve, Housing: None, Coil: Not Included

SV4-10-C-0-00 SV4-10-C Series Cartridge Valve

565537

None

Not Included

Buna-N

Product Questions & Answers (3)

Question by: Bobby C on Apr 30, 2025, 1:35 PM
runs at 230VAC so this'll work on standard European voltage setups, but what's the actual flow capacity on this thing and can it handle the pressure we're running at 3000 PSI?
Answer by: Customer Support on May 1, 2025, 9:23 PM
Rated right at 6 GPM and holds up to 3000 PSI, so if you're sitting at that pressure ceiling you're at the limit but within spec. Keep in mind that performance data is based on fluid at 105 SSU viscosity and 120 degrees Fahrenheit, so conditions outside that range may affect how it behaves in practice.
Question by: Hank E on Nov 15, 2025, 8:45 PM
got a simple question. when it aint powered up, does this valve shut flow off both ways or just one direction?
Answer by: Customer Support on Nov 17, 2025, 6:56 AM
In the de-energized state it blocks flow in both directions. When you energize the solenoid, the spool lifts and then flow can go either direction through the cartridge.
Question by: Eddie K on Jun 16, 2025, 8:11 AM
Is this here valve gonna fit right into a C-10-2 cavity?
Answer by: Customer Support on Jun 18, 2025, 7:27 AM
Yes, ma'am, it's made to fit a C-10-2 size cavity. You'll need to get the housing separate, though.
