SV4-8-3 Series 3-Way, 2-Position, Solenoid Cartridge Valve, Housing: None, Coil: 24VDC with Deutsch connector and with arc suppression diode

The SV4-8-3 Series 3-Way, 2-Position, Solenoid Cartridge Valve, Housing: None, Coil: 24VDC with Deutsch connector and with arc suppression diode is an essential component designed for demanding mobile and industrial applications, including harvesters and refuse haulers.

This solenoid valve offers a 350 bar (5000 psi) maximum pressure capability with a 227 L/min (60 USgpm) flow rating. It operates directly, ensuring reliability and efficiency under high pressure conditions. The robust construction features hardened and ground steel, ensuring durability and longevity.

In the de-energized state, flow is permitted from port 2 to port 1 while port 3 remains blocked. When energized, the flow shifts from port 2 to port 3, with port 1 blocked, making it highly adaptable for various hydraulic systems. Suitable for 24VDC operations with a Deutsch connector, the valve includes an arc suppression diode for enhanced performance.

It is designed to fit into a C-8-3 cavity and requires ISO 4406 cleanliness level 18/16/13 filtration. The internal leakage stands at a maximum of 5 insup3; per minute at 3000 PSI.

Operating effectively across a temperature range of -40deg;F to 248deg;F, this solenoid valve ensures dependable performance under extreme conditions.

MPN: SV4-8-3-0-24BNS

Supplier Part Number: 02-198050
