main product photo

SV5-8-C Series 2-Way, 2-Position, Normally Closed Solenoid Cartridge Valve, Housing: None, Coil: Not Included

Ask A Question

Description & Features

The Danfoss -Hydraulics SV5-8-C Series Cartridge Valve is designed for versatile applications in harvesters, refuse haulers, as well as mobile and industrial environments. This 2-way, 2-position, normally closed solenoid cartridge valve operates efficiently with 350 bar (5000 psi) pressure and a flow rating of 6 GPM.

The valve features a robust, hardened and ground steel construction, ensuring durability and reliable performance. In the de-energized state, it blocks flow from port 2 to port 1, while allowing free flow from port 1 to port 2. When energized, it restricts flow from port 1 to port 2 and permits free flow from port 2 to port 1.

Installation is simplified with its screw-in cartridge type, and it is designed to fit cavity size C-8-2. To maintain optimal performance, a recommended filtration level of ISO 4406 Cleanliness Level 18/16/13 or cleaner is advised. The valve employs Buna-N seals and is rated for temperatures ranging from -40deg;F to 248deg;F.

**Model Number:** SV5-8-C-0-00

**Supplier Part Number:** 02-160759

Specifications

Application
Harvesters, refuse haulers, mobile and industrial applications
Check Valve
No
Coil
Not Included
Coil Series
8 series, 20 W
Diode
No
Brand
Danfoss – Hydraulics
Brand
Danfoss Power Solutions
Pack Size
1.00
UOM
EA
Features
350 bar (5000 psi) & 227 L/min (60 USgpm)|Reliable, economical and compact|Hardened and ground steel
Housing
None
Installation Type
Screw-in Cartridge
Manual Override Option
No
Number of Housing Ports
2
Number of Valve Ports
2
Port Type
Cartrige Only
Recommended Filtration Level
18/16/13
Seal Material
Buna-N
Seal Type
Buna-N
Special Features
None
Style
2-Way 2-Position Normally Closed
Supplier Part Number
02-160759
Switch Connector
No
Valve Material
Cartridge only
Voltage
volt
Product Weight
0.22 lbs
Alternate Part Numbers
Alternate Part Number C1ZZ82, Alternate Part Number MINO-00900H34479, Alternate Part Number SV58C000

Related Documents

Similar Products

Model Number Part Number Manual Override Option Housing Coil Seal Material Price Action
SV5-8-C Series 2-Way, 2-Position, Normally Closed Solenoid Cartridge Valve, Housing: None, Coil: Not Included

SV5-8-C-0-00 SV5-8-C Series Cartridge Valve

02-160759

None

Not Included

Buna-N

Product Questions & Answers (4)

Question by: Duane E on Feb 25, 2026, 12:03 PM
how tight is the seal on this valve when its closed up? worried about leakby on a mobile setup
Answer by: Customer Support on Feb 27, 2026, 6:56 AM
At 3000 PSI you are looking at a maximum internal leakage of less than 5 drops per minute. It uses standard Buna-N seals to keep things restricted when in the de-energized position blocking flow from port 2 to 1.
Question by: Judy H on Oct 17, 2025, 8:58 PM
does this valve come with the coil and housing, or is that all bought separate?
Answer by: Customer Support on Oct 19, 2025, 2:21 PM
The cartridge itself is what you get here. No coil, no housing included. Both are sold separately, and the valve requires a machined cavity sized C-8-2 for installation. Worth making sure you have that cavity ready before ordering, or picking up the matching housing at the same time.
Question by: Tammy B on Dec 6, 2025, 6:48 PM
putting this on a little harvester manifold, what all do i need besides the cartridge itself?
Answer by: Customer Support on Dec 8, 2025, 6:40 PM
For installation you will need a machined cavity or housing in the C-8-2 cavity size, since the valve is a screw-in cartridge and the housing is not included. You will also need a compatible coil because this part ships without a coil.
Question by: Wayne P on Jan 6, 2026, 6:59 AM
Will this valve work on a harvester?
Answer by: Customer Support on Jan 8, 2026, 6:53 AM
Yes, this Danfoss SV5-8-C series cartridge valve is suitable for use in harvesters, refuse haulers, and other mobile and industrial applications.
