SV5-8-O Series 2-Way, 2-Position, Normally Open Solenoid Cartridge Valve, Housing: None, Coil: Not Included

Ask A Question

Description & Features

The SV5-8-O Series 2-Way, 2-Position, Normally Open Solenoid Cartridge Valve is designed for reliable performance in demanding mobile and industrial applications, including harvesters and refuse haulers. Engineered with a pressure rating of 3000 PSI, this cartridge valve ensures robust functionality under high pressure conditions.

Featuring a flow rating of 6 GPM, it operates efficiently within a temperature range of -40deg;F to 248deg;F. This model allows free flow from port 2 to port 1 and restricted flow from port 1 to port 2 in the de-energized position; conversely, the energized position blocks flow from port 2 to port 1 and permits free flow from port 1 to port 2.

Constructed from hardened and ground steel, this cartridge valve is both durable and compact, making it an economical solution for various hydraulic systems. The valve's internal leakage is measured at less than 5 drops per minute maximum at 3000 PSI when energized, ensuring efficient operation.

Segment Code: seg_code_a

Model Number: SV5-8-0-0-00

Supplier Part Number: 02-160761

Specifications

Application
Harvesters, refuse haulers, mobile and industrial applications
Check Valve
No
Coil
Not Included
Coil Series
8 series, 20 W
Diode
No
Brand
Danfoss – Hydraulics
Brand
Danfoss Power Solutions
Pack Size
1.00
UOM
EA
Features
350 bar (5000 psi) & 227 L/min (60 USgpm)|Reliable, economical and compact|Hardened and ground steel
Housing
None
Installation Type
Screw-in Cartridge
Manual Override Option
No
Number of Housing Ports
2
Number of Valve Ports
2
Port Type
Cartrige Only
Recommended Filtration Level
18/16/13
Seal Material
Buna-N
Seal Type
Buna-N
Special Features
None
Style
2-Way 2-Position Normally Open
Supplier Part Number
02-160761
Switch Connector
No
Valve Material
Cartridge only
Product Weight
0.29 lbs
Alternate Part Numbers
Alternate Part Number C1AD17, Alternate Part Number MINO-00569H15249, Alternate Part Number SV580000

Related Documents

Similar Products

Model Number Part Number Manual Override Option Housing Coil Seal Material Price Action
SV5-8-O Series 2-Way, 2-Position, Normally Open Solenoid Cartridge Valve, Housing: None, Coil: Not Included

SV5-8-0-0-00 SV5-8-O Series Cartridge Valve

02-160761

None

Not Included

Buna-N

Product Questions & Answers (1)

Question by: Brent B on Feb 6, 2026, 7:18 PM
got a valve bank that takes C-8-2 cavities. is this the normally open screw-in cartridge for that, or am i mixin it up?
Answer by: Customer Support on Feb 8, 2026, 6:23 PM
The SV5-8-O is a screw-in cartridge valve that installs in a machined C-8-2 cavity or housing. Keep in mind it is cartridge only on this SKU, so the housing and the coil are both sold separately.
