main product photo

SV9-10 Series 4-Way, 3-Position Solenoid Cartridge Valve, Tandem Center, Housing: None, Coil: Not Included

Ask A Question

Description & Features

The SV9-10 Series 4-Way, 3-Position Solenoid Cartridge Valve, Tandem Center, is designed to operate in complex hydraulic systems for mobile and industrial applications, such as harvesters and refuse haulers. It functions efficiently at a pressure rating of 3000 PSI, with a maximum internal leakage of 15 insup3; per minute at 3000 PSI. Made from hardened and ground steel, this valve is reliable, economical, and compact.

The valve features a direct-acting mechanism and operates with four ports: in the de-energized position, tandem center valves permit flow from port 3 to port 1 while blocking ports 2 and 4. When solenoid 1 is energized, flow is redirected from port 3 to port 2 and port 4 to port 1. When solenoid 2 is energized, flow moves from port 3 to port 4 and port 2 to port 1.

This cartridge-style valve is compatible with a J Series 20 Watt coil, sold separately. The recommended filtration level is 18/16/13 microns according to ISO 4406 cleanliness standards. The valve operates effectively within an extreme temperature range of -40deg;F to 248deg;F and requires screw-in cartridge installation.

Model Number: SV910NA00000000000000A

Supplier Part Number: 02-199325

Specifications

Application
Harvesters, refuse haulers, mobile and industrial applications
Check Valve
No
Circuit Type
Tandem Center
Coil
Not Included
Diode
No
Brand
Danfoss – Hydraulics
Brand
Danfoss Power Solutions
Pack Size
1.00
UOM
EA
Features
350 bar (5000 psi) & 227 L/min (60 USgpm)|Reliable, economical and compact|Hardened and ground steel
Housing
None
Installation Type
Screw-in Cartridge
Leakage
Standard
Manual Override Option
No
Number of Housing Ports
4
Number of Valve Ports
4
Operation
Direct Acting
Port Type
Cartrige Only
Recommended Filtration Level
18/16/13 microns
Seal Material
Buna-N
Seal Type
Buna-N
Special Features
None
Style
4-Way 3-Position
Supplier Part Number
02-199325
Switch Connector
No
Valve Material
Cartridge only
Product Weight
0.52 lbs
Alternate Part Numbers
Alternate Part Number 565549, Alternate Part Number C1BT30, Alternate Part Number C1KY86, Alternate Part Number DSSV910A000, Alternate Part Number MINO-00569H80211, Alternate Part Number SV910A000, Alternate Part Number SV910NA00000000000000A

Related Documents

Similar Products

Model Number Part Number Circuit Type Housing Coil Seal Material Price Action
SV9-10 Series 4-Way, 3-Position Solenoid Cartridge Valve, P Blocked, A&B Open to Tank, Housing: None, Coil: Not Included

SV910NF00000000000000A SV9-10 Series Cartridge Valve

02-199329

P Blocked, A&B Open to Tank

None

Not Included

Buna-N

SV9-10 Series 4-Way, 3-Position Solenoid Cartridge Valve, Tandem Center, Housing: None, Coil: Not Included

SV910NA00000000000000A SV9-10 Series Cartridge Valve

02-199325

Tandem Center

None

Not Included

Buna-N

Product Questions & Answers (3)

Question by: Hugh H on May 16, 2025, 8:43 AM
does this valve come with the coil or housing, or do i need to track those down separate?
Answer by: Customer Support on May 17, 2025, 7:17 PM
The cartridge itself is what you get here. No coil and no housing are included. You'll need a J Series 20 Watt coil and a separate housing with a C-10-4 cavity size, both sold separately. Worth making sure you've got those lined up before installation since the cartridge won't function without them.
Question by: Floyd T on Apr 24, 2025, 7:55 AM
What kind of machines would use this valve?
Answer by: Customer Support on Apr 26, 2025, 8:28 AM
Application-wise, this valve is often found in mobile and industrial hydraulic systems, like the ones used in harvesters and refuse haulers.
Question by: Shane M on Mar 8, 2026, 11:00 AM
got a tandem center setup here, when neither coil is powered what’s this valve doing with the ports?
Answer by: Customer Support on Mar 10, 2026, 10:14 AM
In the de-energized position on the tandem center version, it lets flow go from port 3 to port 1 and it blocks ports 2 and 4. When you energize solenoid 1, it routes 3 to 2 and 4 to 1. When you energize solenoid 2, it routes 3 to 4 and 2 to 1.
