SV9-8 Series 4-Way, 3-Position, Solenoid Cartridge Valve, P Blocked, A&B Open In Center Position, Housing: None, Coil: Not Included

Description & Features

The Vickers by Danfoss/Eaton SV9-8 Series is a 4-Way, 3-Position Solenoid Cartridge Valve designed for demanding applications such as harvesters, refuse haulers, and various mobile and industrial environments. This valve features a "P Blocked, A&B Open" circuit type in the center position and operates efficiently under a maximum pressure rating of 3000 PSI. Crafted from hardened and ground steel, it offers durability and reliability.

With a flow rating of up to 227 L/min (60 USgpm) and a temperature range of -40°F to 248°F, it meets the rigorous demands of extreme conditions. This valve is compatible with Cavity size C-8-4 housings, sold separately, and requires a P Series 20 Watt coil, also sold separately. For optimal performance, maintain ISO 4406 cleanliness level 18/16/13 or cleaner.

SKU: 02-198685

Supplier Part Number (MPN): 02-198685

Alternate Part Numbers: C1HW91, SV98NF00000000000000

Specifications

Application Harvesters, refuse haulers, mobile and industrial applications	Check Valve No	Circuit Type P Blocked, A&B Open	Coil Not Included	Diode No	Brand Danfoss – Hydraulics	Brand Danfoss Power Solutions	Pack Size 1.00	UOM EA	Features 350 bar (5000 psi) & 227 L/min (60 USgpm)\|Reliable, economical and compact\|Hardened and ground steel	Housing None	Manual Override Option No	Seal Material Buna-N	Special Features None	Style 4-Way 3-Position	Supplier Part Number 02-198685	Switch Connector No	Product Weight 0.50 lbs	Alternate Part Numbers Alternate Part Number C1HW91, Alternate Part Number MINO-00569H92493, Alternate Part Number SV98NF00000000000000

Product Questions & Answers (4)

Question by: Dwight F on Dec 29, 2025, 6:12 PM

how hot or cold can this valve run before the seals give out

Answer by: Customer Support on Dec 30, 2025, 8:52 PM

Extreme limits for the Buna-N seals range from 40 degrees below zero up to 248 degrees Fahrenheit. Keeping your fluid within those boundaries helps get the best lifespan out of the internal cartridge.

Question by: Hubert G on Feb 1, 2026, 8:48 PM

got a valve body already, what cavity does this SV9-8 cartridge screw into?

Answer by: Customer Support on Feb 3, 2026, 7:01 PM

The SV9-8 series uses a C-8-4 cavity, and the housing for that cavity is sold separately since this SKU is the cartridge only.

Question by: Cody F on Jan 25, 2026, 7:03 PM

What size cavity is needed for this valve?

Answer by: Customer Support on Jan 27, 2026, 10:21 AM

This cartridge fits a C-8-4 size cavity. Keep in mind the housing is sold separately.

Question by: Daryl J on Jan 30, 2026, 8:05 AM

what all does this valve come with out of the box, or do you have to buy the coil and housing separate?

Answer by: Customer Support on Jan 31, 2026, 2:16 PM

Just the cartridge itself ships with this part. The coil and housing are both sold separately. You'll need a C-8-4 cavity size housing and a P Series 20 Watt coil to get a complete, working assembly. Worth planning for those add-ons before you order if you're trying to get up and running quick.
