Thermoplastic Polyester Tube, Black Cover SAE 100R1/SAE 100R7 Hose, Up To 3250 PSI

Description & Features

Application	Lubrication systems. General mobile hydraulics. Agriculture equipment. Please review the general guidelines for selection, installation and maintenance of hose assemblies starting on
Construction	Polyester tube. Braided, bronze-coated steel wire reinforcement. Black non-perforated, polyurethane cover.
Features	Meets or exceeds SAE 100R1 and 100R7 performance specifications. Steel wire reinforcement. Cut resistant, heavy-duty design. Crush resistant.
Fittings	Synflex® Swage 3903 Series (Steel). Synflex® Swage 390A Series (Stainless Steel)
Temperature Range	-40°F to +225°F (-40°F to +140°F with water-based, or fire-resistant, fluids)

Model Number	Hose I.D.	Hose O.D.	Maximum Operating Pressure	Burst Pressure	Minimum Bend Radius	Reel Qty (ft)	Price	Action
3580-06004 Thermoplastic SAE 100R1/R7 Hose	0.38	0.65	3250		2.25	500
