VD10A Series Assembling kit for 2 section valve assembly

Designed for two-section valve assembly configurations, the Salami VD10A Series Assembling Kit provides the hardware needed to correctly join and seal multi-section directional control valve assemblies within hydraulic circuits. Manufactured by Salami S.P.A., this kit is built to the tolerances required by the VD10A valve series and supports system flow rates up to 32 GPM.

The kit is rated for maximum operating pressures of 4000 PSI at the pressure port and 4500 PSI at working ports A and B, with a maximum back pressure of 363 PSI at the tank port. Fluid temperature compatibility spans -4°F to 185°F with standard NBR seals, and optimal fluid viscosity falls between 12 cSt and 75 cSt. Recommended filtration is ISO 4406: 19/16, consistent with the test conditions used for all published performance data. Ambient operating temperature range is 86°F to 140°F.

SKU: R22085120

Supplier Part Number (MPN): R22085120

Alternate Part Numbers: C1MT54
