VD10A Series SALAMI BOLT KIT. 4 SECTION. FITS SALAMI

Designed for use with Salami VD10A Series directional control valves, the VD10A Series Salami Bolt Kit provides the hardware needed to assemble a 4-section valve stack. Rated for maximum operating pressures of 4,000 PSI on pressure ports and 4,500 PSI on work ports, this kit is built to handle demanding hydraulic circuit requirements.

Compatible with fluid temperatures ranging from -4°F to 185°F using standard NBR seals, and suited to ambient temperatures between 86°F and 140°F, the kit supports systems running mineral oil at viscosities between 12 cSt and 75 cSt optimal. Back pressure on the outlet port is rated to 363 PSI, and recommended filtration is ISO 4406: 19/16. Technical data is based on mineral oil at 16 cSt with contamination level 19/16 per ISO 4406.

SKU: R22085140

Supplier Part Number (MPN): R22085140

Alternate Part Numbers: C1MT56
