VD10A Series Assembling kit for 5 section valve assembly

Description & Features

Designed to complete a five-section directional control valve stack, the VD10A Series Assembling kit for 5 section valve assembly is a genuine Salami S.P.A. component engineered to meet the assembly requirements of VD10A Series valve configurations. The kit supports a maximum operating pressure of 4,000 PSI on the pressure port and up to 4,500 PSI on the work ports, with a flow rating of 32 GPM and a maximum back pressure of 363 PSI on the tank port.

Compatible with mineral oil at a recommended viscosity range of 12 cSt to 75 cSt, the assembly is rated for fluid temperatures from -4°F to 185°F with standard NBR seals, and ambient temperatures up to 140°F. Recommended system filtration is ISO 4406: 19/16. Internal leakage is rated at 2.43–3.34 in³/min. at 2,285 PSI under standard test conditions using mineral oil at 16 cSt.

SKU: R22085150

Supplier Part Number (MPN): R22085150

Alternate Part Numbers: C1MT57

Specifications

Brand Salami S.P.A	Brand Salami S.P.A	Pack Size 1.00	UOM EA	Supplier Part Number R22085150	Alternate Part Numbers Alternate Part Number C1MT57	Product Weight 1.50 lbs

Product Questions & Answers (1)

Question by: Carl M on Dec 18, 2025, 12:30 PM

What kind of oil should I be running in a setup like this?

Answer by: Customer Support on Dec 19, 2025, 4:02 PM

Optimal performance calls for mineral oil with a viscosity between 12 cSt and 75 cSt. You can push it a bit, but try to stay between 10 cSt and 460 cSt.
