Main relief valve (VS) adjustable 1500 PSI to 3000 PSI

Part of the Salami VD10A Series inlet module lineup, this Main Relief Valve (VS) Adjustable 1500 PSI to 3000 PSI is designed for use in directional control valve assemblies requiring configurable system pressure management. The adjustable range covers 1500 to 3000 PSI, with a maximum operating pressure of 4000 PSI on the inlet port and up to 4500 PSI on working ports.

Rated for flows up to 32 GPM, this inlet module accommodates fluid temperatures from -4°F to 185°F with standard NBR seals and supports fluid viscosities from 10 cSt minimum up to 460 cSt maximum. Maximum back pressure on the outlet port is 363 PSI. Recommended filtration is ISO 4406: 19/16, and all published performance data is based on mineral oil at 16 cSt viscosity.

SKU: R22070030

Supplier Part Number (MPN): R22070030

Alternate Part Numbers: C1MT46
