Port relief valve (VA) adjustable 725 PSI to 1525 PSI

Description & Features

Designed for precision pressure control, the Salami VD10A Series Port Relief Valve (VA) is adjustable from 725 PSI to 1525 PSI, making it ideal for hydraulic systems where precise pressure regulation is crucial. This valve can handle a maximum operating pressure of 4000 PSI on ports "P" and 4500 PSI on ports "A" and "B", ensuring robust performance even under demanding conditions.

With a flow rating of 32 GPM and an internal leakage rate of 2.43 - 3.34 in³/min at 2285 PSI, this valve offers reliable performance and efficiency. The valve operates effectively within a fluid temperature range of -4°F to 185°F when equipped with standard NBR seals, and is compatible with fluid viscosities from 12 cSt to 75 cSt, with a recommended filtration level of ISO 4406: 19/16. Suitable for various industrial applications, this valve withstands ambient temperatures from 86°F to 140°F and a maximum back pressure of 363 PSI on outlet port "T".

SKU: R22078410

Supplier Part Number (MPN): R22078410

Alternate Part Numbers: C1MT50

Specifications

Brand Salami Hydraulics Na Inc	Brand Salami S.P.A	Pack Size 1.00	UOM EA	Supplier Part Number R22078410	Alternate Part Numbers Alternate Part Number C1MT50	Product Weight 0.43 lbs

Product Questions & Answers (1)

Question by: Steve G on Jul 19, 2025, 2:41 PM

What’s the deal with the operating temps for this valve? I see two different numbers listed.

Answer by: Customer Support on Jul 21, 2025, 2:22 PM

The fluid temperature range is -4°F to 185°F when using standard NBR seals. The ambient temperature range, which is the temperature of the surrounding environment, is 86°F to 140°F.
