Port relief valve (VA) adjustable 1525 PSI to 3000 PSI

Optimize your hydraulic system with the Salami VD10A Series port relief valve, adjustable from 1525 PSI to 3000 PSI. This robust component is engineered to handle a maximum operating pressure of 4000 PSI on ports "P" and 4500 PSI on ports "A" and "B". It offers a flow rating of 32 GPM, ensuring efficient performance in demanding applications. With an internal leakage rate of 2.43 - 3.34 in³/min at 2285 PSI, it is designed for precision and reliability.

The valve operates effectively within a fluid temperature range of -4°F to 185°F, supported by standard NBR seals, and is best suited for fluids with viscosities between 12 cSt to 75 cSt. It also maintains performance with a maximum back pressure of 363 PSI on the outlet port "T". Recommended filtration adheres to ISO 4406: 19/16 standards, ensuring optimal operation.

SKU: R22078420

Supplier Part Number (MPN): R22078420

Alternate Part Numbers: C1MT51
