Joystick control for two spools (L1/L2)

Description & Features

Part of the Salami Vd10a Series, this joystick control for two spools (L1/L2) is designed for directional control applications requiring precise two-axis operator input. It is rated for flows up to 32 GPM and handles maximum operating pressures of 4000 PSI on the pressure port and 4500 PSI on the work ports, making it well suited for demanding mobile hydraulic circuits.

The unit accepts fluid temperatures from -4°F to 185°F with standard Nbr seals and operates within an ambient temperature range of 86°F to 140°F. Optimal fluid viscosity falls between 12 cSt and 75 cSt. Recommended system filtration is ISO 4406: 19/16. Technical data is based on mineral oil at 16 cSt with contamination level 19/16 per ISO 4406. The catalog reference for this control is C1Mt63.

SKU: R22187840

Supplier Part Number (MPN): R22187840

Alternate Part Numbers: C1MT63

Specifications

Brand Salami S.P.A	Pack Size 1.00	UOM EA	Supplier Part Number R22187840	Alternate Part Numbers Alternate Part Number C1MT63	Product Weight 1.25 lbs

Product Questions & Answers (1)

Question by: Troy W on Jan 24, 2026, 6:02 AM

What kind of fluid is this joystick control set up for? I'm running mineral oil.

Answer by: Customer Support on Jan 25, 2026, 11:55 AM

All the technical specs for this control are based on mineral oil with a viscosity of 16 cSt and a contamination level of 19/16 as per ISO 4406, so you should be good to go.
