Detent kit (R5) position 2

The Salami VD10A Series Detent Kit offers precision and reliability for hydraulic systems operating under demanding conditions. Designed for optimal performance within a fluid temperature range of -4°F to 185°F, this kit accommodates fluid viscosities from 12 cSt to 75 cSt, ensuring smooth operation with minimal internal leakage of 2.43 - 3.34 in³/min at 2285 PSI. It supports a maximum flow rate of 32 GPM and can handle operating pressures up to 4000 PSI on ports "P" and 4500 PSI on ports "A" and "B".

Engineered for durability, the detent kit maintains its integrity with a maximum back pressure of 363 PSI on the outlet port "T". Recommended for use with mineral oil, it conforms to ISO 4406 standards with a contamination level of 19/16 and requires efficient filtration to sustain hydraulic performance. This kit is an essential component for maintaining the efficiency and longevity of hydraulic systems utilizing the Salami VD10A Series.

SKU: R22400509

Supplier Part Number (MPN): R22400509

Alternate Part Numbers: C1MT66
