SALAMI VD10A-P02A-PRA.PRB-MLA-C2/S PARAL

Description & Features

The Salami VD10A Series Working Section is expertly designed for demanding hydraulic applications, offering a substantial maximum operating pressure of 4000 PSI on port "P" and 4500 PSI on ports "A" and "B". This robust component is ideal for systems requiring efficient flow handling, with a flow rating of 32 GPM. The VD10A series ensures optimal performance in various temperature conditions, operating smoothly between -4°F to 185°F with standard NBR seals. Its internal leakage is efficiently controlled, ranging from 2.43 to 3.34 in³/min at 2285 PSI, ensuring system integrity and reliability.

Engineered with precision, this working section can handle a maximum back pressure of 363 PSI on outlet port "T". It is recommended for use with mineral oil of 16 cSt viscosity and a contamination level of 19/16 as per ISO 4406 standards, which also guides the necessary filtration. The Salami VD10A-P02A-PRA.PRB-MLA-C2/S PARAL is a reliable choice for maintaining consistent hydraulic performance.

SKU: S22081501

Supplier Part Number (MPN): S22081501

Alternate Part Numbers: C1MW37

Specifications

Brand Salami Hydraulics Na Inc	Brand Salami Hydraulics	Pack Size 1.00	UOM EA	Supplier Part Number S22081501	Alternate Part Numbers Alternate Part Number C1MW37	Product Weight 11.20 lbs

Similar Products

Model Number	Product Description	Price	Action
R22176331 VD10A Series Working Section	SALAMI VD10A-VD12A PP KIT 1/8 NPT PORTS.
R22400309 VD10A Series Working Section	SALAMI VD10A-VD12A R2 DETENT KIT.
S22081501 VD10A Series Working Section	SALAMI VD10A-P02A-PRA.PRB-MLA-C2/S PARAL.
R22470081 VD10A Series Working Section	SALAMI VD10A-VD12A P ( 50 - 280 ) PILOT.
R360T0500 VD10A Series Working Section	SALAMI VD10/VD12 CABLE CONTROL.
S22081391 VD10A Series Working Section	SALAMI VD10A-P01A-PRA.PRB-MLA-C2/S PARAL.

Product Questions & Answers (3)

Question by: Brett G on Nov 4, 2025, 7:06 AM

got a system that runs around 3,000 psi most days. what pressure can this valve handle on the different ports

Answer by: Customer Support on Nov 6, 2025, 6:14 AM

Pressure limits depend on which port you are loading. Ports P are rated up to 4000 PSI, while ports A and B are rated up to 4500 PSI.

Question by: Travis B on Mar 22, 2026, 10:52 AM

What kind of oil should I be using in this valve?

Answer by: Customer Support on Mar 24, 2026, 9:02 AM

Optimal fluid viscosity for this Salami valve is between 12 cSt and 75 cSt. It was tested using mineral oil with a viscosity of 16 cSt and contamination level 19/16 as ISO 4406.

Question by: Sherry F on Nov 23, 2025, 2:10 PM

i got a system that runs about 32 gpm, is this VD10A section gonna choke it down any?

Answer by: Customer Support on Nov 25, 2025, 12:07 PM

Flow-wise, it is rated for 32 GPM, so that matches what you are running. Just keep the oil in the stated viscosity window, with 12 to 75 cSt being the sweet spot, and filtration around ISO 4406 19/16 since the published performance data is based on that kind of oil cleanliness.
