VD12A Series Section seal kit

Description & Features

Designed for the Salami Hydraulics Na Inc VD12A Series directional control valves, this section seal kit supports maximum operating pressures of 4000 PSI on P ports and 4500 PSI on A and B ports, with a maximum back pressure of 363 PSI on the outlet T port. Standard NBR seals accommodate fluid temperatures from -4°F to 185°F and ambient temperatures from 86°F to 140°F.

The VD12A Series Section Seal Kit is rated for flow up to 48 GPM, with an optimal fluid viscosity range of 12 to 75 cSt and a working minimum of 10 cSt. Recommended filtration is ISO 4406: 19/16, and all technical data is referenced using mineral oil at 16 cSt with a contamination level of 19/16 per ISO 4406. Internal leakage is rated at 2.43–3.34 in³/min. at 2285 PSI.

SKU: R22472529

Alternate Part Numbers: C1MT71

Specifications

Brand Salami Hydraulics Na Inc	Brand Salami Hydraulics	Pack Size 1.00	UOM EA	Supplier Part Number R22472529	Alternate Part Numbers Alternate Part Number C1MT71	Product Weight 0.01 lbs

Product Questions & Answers (3)

Question by: Peggy C on Sep 5, 2025, 5:01 PM

Will this section seal kit work as a replacement for the VD12A series?

Answer by: Customer Support on Sep 6, 2025, 8:14 PM

This section seal kit is designed specifically for the VD12A series.

Question by: Dustin J on May 24, 2025, 8:35 PM

How do I know if this VD12A Series Section seal kit will fit my equipment?

Answer by: Customer Support on May 26, 2025, 6:27 AM

This section seal kit is specifically made for the VD12A series, so you'll want to check if your equipment is part of that series to ensure a proper fit.

Question by: Marvin R on Aug 5, 2025, 8:28 AM

what all comes in this seal kit for the VD12A

Answer by: Customer Support on Aug 7, 2025, 6:04 AM

Unfortunately, the available product information doesn't specify which individual seals or components are included in this VD12A Series section seal kit. You'd need to check with the supplier directly to get the complete parts list and confirm what seals are packaged together in this particular kit.
