VD12A Series Salami VD12A/3 SECTION BOLT Kit

Description & Features

This Salami VD12A Series VD12A/3 SECTION BOLT Kit is designed for robust hydraulic performance. It is built to withstand a maximum operating pressure of 4000 PSI on ports "P" and 4500 PSI on ports "A" and "B". The kit is engineered to maintain optimal fluid viscosity between 12 cSt and 75 cSt, with a minimum of 10 cSt and a maximum of 460 cSt.

The VD12A Series assembly kit is suitable for use in ambient temperatures ranging from 86°F to 140°F. The recommended filtration follows ISO 4406: 19/16 standards to ensure system cleanliness and longevity. The flow rating is 48 GPM, and it can function with a fluid temperature range of -4°F to 185°F when using standard NBR seals.

SKU: R22485039

Supplier Part Number (MPN): R22485039

Alternate Part Numbers: C1MT77

Specifications

Brand Salami Hydraulics Na Inc	Brand Salami Hydraulics	Pack Size 1.00	UOM EA	Supplier Part Number R22485039	Alternate Part Numbers Alternate Part Number C1MT77	Product Weight 1.45 lbs

Similar Products

Model Number	Product Description	Price	Action
R22485029 VD12A Series Assembly Kit	SALAMI VD12A/2 SECTION BOLT KIT.
R22485019 VD12A Series Assembly Kit	SALAMI VD12A/1 SECTION BOLT KIT.
R22485039 VD12A Series Assembly Kit	SALAMI VD12A/3 SECTION BOLT KIT.

Product Questions & Answers (3)

Question by: Roy H on Sep 3, 2025, 8:44 AM

What’s the ambient temperature range this kit can handle?

Answer by: Customer Support on Sep 4, 2025, 9:13 PM

The Salami VD12A/3 SECTION BOLT Kit is designed to function in ambient temperatures from 86°F up to 140°F.

Question by: Sheila R on Aug 21, 2025, 4:51 PM

what's the max pressure this bolt kit can handle on the work ports, and does that differ from the pressure rating on the inlet?

Answer by: Customer Support on Aug 23, 2025, 8:59 AM

Port pressure ratings do vary across the assembly. The "P" inlet port is rated to 4000 PSI, while the "A" and "B" work ports can handle up to 4500 PSI. Back pressure on the outlet "T" port tops out at 363 PSI, so that one has a much lower ceiling than the others. Keep all three limits in mind when sizing this into your system.

Question by: Pete H on Jan 18, 2026, 9:59 PM

got a VD12A stack that uses the 3 section bolts. is this the right kit, or is it something else

Answer by: Customer Support on Jan 20, 2026, 6:05 AM

For VD12A series assemblies that call for the VD12A/3 section bolt setup, this is the matching VD12A/3 SECTION BOLT kit. It is identified as Salami part number R22485039, with alternate catalog number C1MT77.
