VD12A Series Assembly kit for 8 section valve assembly

Designed for use with 8-section directional control valve assemblies, the VD12A Series Assembly Kit from Salami S.P.A. provides the seals and hardware needed to properly service or complete a multi-section valve build. The kit is rated for fluid temperatures from -4°F to 185°F with standard NBR seals, and supports a fluid viscosity range of 12 to 75 cSt under optimal conditions, with a tested maximum of 460 cSt.

Maximum operating pressure reaches 4,000 PSI on the pressure port and 4,500 PSI on the actuator ports, with a maximum back pressure of 363 PSI on the outlet port. Flow capacity is rated at 48 GPM. Technical data is based on mineral oil at 16 cSt viscosity and a contamination level of ISO 4406: 19/16, which is also the recommended filtration standard for this assembly.

SKU: R22485089

Supplier Part Number (MPN): R22485089

Alternate Part Numbers: C1MT82
