VD6A Series Kit for 2-section valve assembly

This VD6A Series Kit is designed for 2-section valve assembly and is part of the Salami Hydraulics VD6A Series. These kits feature cast-iron bodies, with options for up to 8 work sections. It offers parallel, series, and tandem circuits, each equipped with load check valve protection. Open and closed center configurations are available, along with power beyond options.

Spools are constructed from hardened steel and nickel-plated, and are interchangeable. Spool selections include double-acting, single-acting, motor, cylinder, and float. Auxiliary valves are available for ports A and B, and several types of mid-inlet modules are offered. A venting valve is also available. Controls include manual, cable, electric, electro-hydraulic, proportional hydraulic, pneumatic, and electro-pneumatic options.

This kit has a flow rating of 12 GPM. It is designed for fluid temperatures from -4°F to 185°F when using standard NBR seals, and an ambient temperature range of -22°F to 140°F. The optimal fluid viscosity ranges from 12 cSt to 75 cSt, with a minimum of 10 cSt and a maximum of 400 cSt. The maximum operating pressure on ports P, A, and B is 5100 PSI, and the maximum back pressure on outlet port T is 363 PSI.

SKU: R23400620

Supplier Part Number (MPN): R23400620

Alternate Part Numbers: C1NC38
