Salami LEVER STICK KNOB And KNOB Kit

Description & Features

The Salami VD6A Series offers robust cast-iron bodies with options for up to 8 work sections. Operating efficiently within an ambient temperature range of -22deg;F to 140deg;F.

Featuring parallel series and tandem circuits each section is protected by a load check valve. The hardened steel and nickel-plated spools are interchangeable with various spool selections such as double acting single acting motor and cylinder. The product includes auxiliary valves for ports A and B several mid-inlet modules and a venting valve.

It supports manual cable electric electro-hydraulic proportional hydraulic pneumatic proportional pneumatic and electro-pneumatic controls. The fluid temperature range is -4deg;F to 185deg;F with standard NBR seals and optimal fluid viscosity ranges from 12 cSt to 75 cSt. It handles a maximum operating pressure of 5100 PSI on ports P A and B and an internal leakage rate of 1.1 - 1.52 insup3;/min. at 2285 PSI.

Maximum back pressure on the outlet port T is 363 PSI and recommended filtration follows ISO 4406: 19/16 standards. All technical data referenced uses mineral oil with a viscosity of 16 cSt and a contamination level of 19/16 as per ISO 4406.

MPN: C1MQ94

Supplier Part Number: 420192000

Specifications

Brand Salami Hydraulics Na Inc	Brand Salami Hydraulics	Pack Size 1.00	UOM EA	Key A side actuator	Supplier Part Number 420192000	Alternate Part Numbers Alternate Part Number C1MQ94	Product Weight 0.14 lbs

Similar Products

Model Number	Key	Product Description
323411302 VD6A Series Working Section	(2)	SALAMI VDM6/VD6 02A M SPOOL.
R23400322 VD6A Series Working Section	(3)	SALAMI CO FRICTION KIT.
796332555 VD6A Series Working Section	B side actuator	SALAMI VDM6/VD6 E9 45W 12V.
R23400060 VD6A Series Working Section	(4)	SALAMI LEVER STICK POSITIONING KIT. PR.
R23400210 VD6A Series Working Section	Spool	SALAMI VDM6/VD6 SPOOL SEAL KIT.
R23400320 VD6A Series Working Section	(3)	SALAMI R2 DETENT KIT.
R23400321 VD6A Series Working Section	B side actuator	SALAMI VDM6/VD6A R9 DETENT KIT.
S23480070 VD6A Series Working Section	(1)	SALAMI VD6A-P01A-PRA.PRB-NLA-C2/S PARALL.
S23480550 VD6A Series Working Section	(1)	SALAMI VD6A-P02A-PRA.PRB-NLA-C2/S PARALL.

Product Questions & Answers (3)

Question by: Darryl C on Nov 12, 2025, 8:33 AM

what kind of controls does this valve setup work with? trying to figure out if it'll play nice with our cable actuators before we order

Answer by: Customer Support on Nov 13, 2025, 4:53 PM

Cable control is one of the supported options on the VD6A Series, along with manual, electric, electro-hydraulic, proportional hydraulic, pneumatic, proportional pneumatic, and electro-pneumatic. So your cable actuators should line up just fine with what this kit is built to accommodate.

Question by: Johnny G on Sep 14, 2025, 12:25 PM

Is this knob kit just for the VD6A series valves?

Answer by: Customer Support on Sep 15, 2025, 4:32 PM

It is designed specifically for the Salami VD6A series working sections.

Question by: Rod J on Sep 18, 2025, 8:28 AM

got a vd6a valve bank, what all control styles does this knob kit work with?

Answer by: Customer Support on Sep 20, 2025, 6:42 AM

For the VD6A Series, the control options called out include manual, cable, electric, electro-hydraulic proportional, hydraulic, pneumatic proportional pneumatic, electro-pneumatic, and electro-pneumatic controls. The item is labeled as an A side actuator lever stick knob and knob kit for that VD6A setup.
