Salami LEVER STICK POSITIONING Kit. PR

Description & Features

Engineered to perform under demanding conditions this kit features cast-iron bodies suitable for temperatures ranging from -22deg;F to 140deg;F. Allowing for parallel series and tandem circuit configurations it includes protection against load checks on each section. Open and closed center options with Power Beyond capabilities are available.

The kit's interchangeable hardened steel spools offer a variety of selections including double acting single acting motor cylinder and float. Auxiliary valves for ports A and B along with multiple mid-inlet modules and a venting valve provide additional flexibility.

Controls can be manual cable electric electro-hydraulic proportional hydraulic pneumatic proportional pneumatic or electro-pneumatic. The flow rating is 12 GPM with optimal fluid viscosity between 12 cSt to 75 cSt and a fluid temperature range from -4deg;F to 185deg;F with standard NBR seals.

Operating pressure reaches up to 5100 PSI on ports P A and B. Internal leakage measures between 1.1 - 1.52 insup3;/min at 2285 PSI with a maximum back pressure of 363 PSI on outlet port T. Recommended filtration is ISO 4406: 19/16 for enhanced efficiency.

MPN: R23400060

Supplier Part Number: R23400060

Specifications

Brand Salami Hydraulics Na Inc	Brand Salami Hydraulics	Pack Size 1.00	UOM EA	Key (4)	Supplier Part Number R23400060	Alternate Part Numbers Alternate Part Number C1MU12, Alternate Part Number MI-02129768, Alternate Part Number MINO-00770X10851	Product Weight 1.00 lbs

Similar Products

Model Number	Key	Product Description
323411302 VD6A Series Working Section	(2)	SALAMI VDM6/VD6 02A M SPOOL.
R23400322 VD6A Series Working Section	(3)	SALAMI CO FRICTION KIT.
420192000 VD6A Series Working Section	A side actuator	SALAMI LEVER STICK KNOB AND KNOB KIT.
796332555 VD6A Series Working Section	B side actuator	SALAMI VDM6/VD6 E9 45W 12V.
R23400060 VD6A Series Working Section	(4)	SALAMI LEVER STICK POSITIONING KIT. PR.
R23400210 VD6A Series Working Section	Spool	SALAMI VDM6/VD6 SPOOL SEAL KIT.
R23400320 VD6A Series Working Section	(3)	SALAMI R2 DETENT KIT.
R23400321 VD6A Series Working Section	B side actuator	SALAMI VDM6/VD6A R9 DETENT KIT.
S23480070 VD6A Series Working Section	(1)	SALAMI VD6A-P01A-PRA.PRB-NLA-C2/S PARALL.
S23480550 VD6A Series Working Section	(1)	SALAMI VD6A-P02A-PRA.PRB-NLA-C2/S PARALL.

Product Questions & Answers (3)

Question by: Randy W on Feb 10, 2026, 5:39 PM

got a machine that sees some cold mornings and hot afternoons. what temps will this valve kit handle?

Answer by: Customer Support on Feb 11, 2026, 8:45 PM

For the valve body itself, the ambient temperature range is -22°F to 140°F. On the hydraulic side, with standard NBR seals the fluid temperature range is -4°F to 185°F.

Question by: Cody H on Nov 8, 2025, 12:16 PM

What kind of control options come with this valve kit, we run both electric and manual setups on different machines and need something that'll work across the board.

Answer by: Customer Support on Nov 10, 2025, 6:41 AM

Pretty flexible on that front. The VD6A Series supports manual, cable, electric, electro-hydraulic, proportional hydraulic, pneumatic, proportional pneumatic, and electro-pneumatic controls. So whether you're running a straight manual lever setup or something with proportional electric control, this kit can be configured to fit either application without needing a completely different valve.

Question by: Curt F on Jan 3, 2026, 6:06 PM

Wondering what kind of fluid viscosity this Salami lever stick kit needs?

Answer by: Customer Support on Jan 5, 2026, 12:28 PM

Optimal fluid viscosity should be between 12 cSt to 75 cSt, though it can handle a minimum of 10 cSt and a maximum of 400 cSt.
