SALAMI R5 DETENT KIT

The Salami R5 Detent Kit, catalog number C1MU16, is designed for use with Salami VD6A series working sections. These sections feature cast-iron bodies and accommodate up to 8 work sections. They are configurable for parallel, series, and tandem circuits, each protected by a load check valve. Open and closed center configurations are supported, with power beyond options available.

Spools are constructed from hardened steel and nickel-plated for durability and are interchangeable, with options including double acting, single acting, motor, cylinder, and float types. Auxiliary valves are available for ports A and B. Mid-inlet modules and venting valves enhance the system's versatility. Control options include manual, cable, electric, electro-hydraulic, proportional hydraulic, pneumatic, proportional pneumatic, and electro-pneumatic.

This kit is designed to operate within a fluid temperature range of -4°F to 185°F using standard NBR seals, and an ambient temperature range of -22°F to 140°F. It supports a flow rating of 12 GPM, with a fluid viscosity range of 12 cSt to 75 cSt (optimal), 10 cSt (minimum), and 400 cSt (maximum). It withstands a maximum operating pressure of 5100 PSI on ports P, A, and B, and a maximum back pressure of 363 PSI on outlet port T.

SKU: R23400250

Supplier Part Number (MPN): R23400250

Alternate Part Numbers: C1MU16
