Salami R2 DETENT Kit

Description & Features

The robust Salami VD6A Series features cast-iron bodies and supports a flow rating of 12 GPM with optimal fluid temperatures ranging from -4deg;F to 185deg;F.

With hardened steel nickel-plated spools and a maximum operating pressure of 5100 PSI this detent kit ensures reliable performance. It includes load check valve protection on each section and can operate efficiently within an ambient temperature range of -22deg;F to 140deg;F.

It offers configurations in parallel series and tandem circuits alongside open and closed center options with Power Beyond. Mid-inlet modules and auxiliary valves for ports A and B enhance its versatility.

The Salami R2 DETENT Kit provides various control options including manual cable electric electro-hydraulic proportional hydraulic pneumatic proportional pneumatic and electro-pneumatic. The interchangeable spools come in selections such as double acting single acting motor cylinder and float.

Venting valves and high-efficiency filtration per ISO 4406: 19/16 specifications contribute to its durability and performance.

MPN: R23400320

Supplier Part Number: R23400320

Specifications

Brand Salami Hydraulics Na Inc	Brand Salami Hydraulics	Pack Size 1.00	UOM EA	Key (3)	Supplier Part Number R23400320	Alternate Part Numbers Alternate Part Number C1MU18	Product Weight 0.39 lbs

Similar Products

Model Number	Key	Product Description
323411302 VD6A Series Working Section	(2)	SALAMI VDM6/VD6 02A M SPOOL.
R23400322 VD6A Series Working Section	(3)	SALAMI CO FRICTION KIT.
420192000 VD6A Series Working Section	A side actuator	SALAMI LEVER STICK KNOB AND KNOB KIT.
796332555 VD6A Series Working Section	B side actuator	SALAMI VDM6/VD6 E9 45W 12V.
R23400060 VD6A Series Working Section	(4)	SALAMI LEVER STICK POSITIONING KIT. PR.
R23400210 VD6A Series Working Section	Spool	SALAMI VDM6/VD6 SPOOL SEAL KIT.
R23400320 VD6A Series Working Section	(3)	SALAMI R2 DETENT KIT.
R23400321 VD6A Series Working Section	B side actuator	SALAMI VDM6/VD6A R9 DETENT KIT.
S23480070 VD6A Series Working Section	(1)	SALAMI VD6A-P01A-PRA.PRB-NLA-C2/S PARALL.
S23480550 VD6A Series Working Section	(1)	SALAMI VD6A-P02A-PRA.PRB-NLA-C2/S PARALL.

Product Questions & Answers (2)

Question by: Ricky A on Aug 22, 2025, 2:39 PM

What's the fluid temperature range on this detent kit, and does it hold up if the hydraulic system runs on the warmer side for long stretches?

Answer by: Customer Support on Aug 24, 2025, 6:56 AM

With standard NBR seals, the fluid temperature range runs from -4°F up to 185°F. That upper limit gives you a reasonable buffer for systems that tend to run warm, though keeping fluid temps consistently near the top of that range will put more wear on the seals over time. For optimal performance, staying within that window rather than pushing right up against 185°F is the smarter play.

Question by: Cindy B on Oct 4, 2025, 11:05 AM

got a VD6A setup on a 12 gpm system, is this detent kit gonna be ok pressure wise?

Answer by: Customer Support on Oct 6, 2025, 6:06 AM

For limits, it is rated up to 5100 PSI on ports P, A, and B, with a max of 363 PSI back pressure on the outlet port T. Flow is listed at 12 GPM for the VD6A series, so it lines up with a 12 GPM system from a capacity standpoint.
