Salami VDM6/VD6A R9 DETENT Kit

Description & Features

The Salami VD6A Series detent kit is designed for high-performance hydraulic systems providing a maximum operating pressure of 5100 PSI on ports P A and B. Its cast-iron bodies and hardened steel nickel-plated spools ensure long-lasting durability. With up to 8 work sections and interchangeable spools it supports configurations such as double acting single acting motor cylinder and float offering flexibility for various applications.

This kit operates effectively within a fluid viscosity range of 12 cSt to 75 cSt and maintains performance in ambient temperatures from -22deg;F to 140deg;F. The fluid temperature range spans from -4deg;F to 185deg;F using standard NBR seals. It also features auxiliary valves for ports A and B multiple mid-inlet modules and a venting valve for enhanced customization.

Parallel series and tandem circuits with Load Check valve protection on each section minimize fluid loss maintaining internal leakage between 1.1 to 1.52 insup3;/min. at 2285 PSI. The design is suited for professional and industrial hydraulic applications needing consistent and reliable performance.

Supplier Part Number: R23400321

Specifications

Brand Salami Hydraulics Na Inc	Brand Salami Hydraulics	Pack Size 1.00	UOM EA	Key B side actuator	Supplier Part Number R23400321	Alternate Part Numbers Alternate Part Number C1MU19, Alternate Part Number MI-02665645, Alternate Part Number MINO-00770X20150	Product Weight 0.22 lbs

Similar Products

Model Number	Key	Product Description
323411302 VD6A Series Working Section	(2)	SALAMI VDM6/VD6 02A M SPOOL.
R23400322 VD6A Series Working Section	(3)	SALAMI CO FRICTION KIT.
420192000 VD6A Series Working Section	A side actuator	SALAMI LEVER STICK KNOB AND KNOB KIT.
796332555 VD6A Series Working Section	B side actuator	SALAMI VDM6/VD6 E9 45W 12V.
R23400060 VD6A Series Working Section	(4)	SALAMI LEVER STICK POSITIONING KIT. PR.
R23400210 VD6A Series Working Section	Spool	SALAMI VDM6/VD6 SPOOL SEAL KIT.
R23400320 VD6A Series Working Section	(3)	SALAMI R2 DETENT KIT.
R23400321 VD6A Series Working Section	B side actuator	SALAMI VDM6/VD6A R9 DETENT KIT.
S23480070 VD6A Series Working Section	(1)	SALAMI VD6A-P01A-PRA.PRB-NLA-C2/S PARALL.
S23480550 VD6A Series Working Section	(1)	SALAMI VD6A-P02A-PRA.PRB-NLA-C2/S PARALL.
